Solar energy system 99% efficiency hybrid MPPT water pump solar inverter
- Category: Solar Pump Inverter >>>
- Supplier: Shenzhen Kewo Electric Technology Co. Ltd.
Share on (60713788390):
Product Overview
Description
Products Description
KEWO SG320 Pump inverter solar pump inverter mainly features:
1. Drives well all kind of AC pump, including PMSM.
2. DC/AC power input.
3. MPPT efficiency more than 99%.
4. Can auto start in the morning if customer required.
5. Bulid in auto sleep-wake up function.
6. Dru run protection, (no need to add sensor).
7. Protect motor well, like over current, over voltage, over load protection.
8. Automatic detection of DC bus voltage, no need set by yourself.
9. Can monitor and control by GPRS (External).
2. DC/AC power input.
3. MPPT efficiency more than 99%.
4. Can auto start in the morning if customer required.
5. Bulid in auto sleep-wake up function.
6. Dru run protection, (no need to add sensor).
7. Protect motor well, like over current, over voltage, over load protection.
8. Automatic detection of DC bus voltage, no need set by yourself.
9. Can monitor and control by GPRS (External).
10. SG320 inverter drives well Single phase pump too.
Input voltage range | 80V to 450VDC input, 3PH 110VAC output, 1S model 150V to 450VDC input, 3PH 220VAC output, 2S/2T model 250V to 800/900VDC input, 3PH 380/440/480VAC output, 4T model |
Recommended input voltage (Voc and Vmp) | Voc 180VDC, Vmp 155VDC for 1S model & 110VAC pumps Voc 370VDC, Vmp 310VDC for 2T model & 220VAC pumps Voc 650VDC, Vmp 540VDC for 4T model & 380VAC pumps |
Motor type | Control for permanent magnet servo motor and asynchronous motor pumps. |
Input power | DC power from solar arrays or AC grid power |
Maximum DC power input | 450VDC for 220AC output & 800/900VDC for 380V AC output, (900V needs remark) |
Rated output voltage | Single phase 220V, 3-phase 220V/380V/480V |
Output frequency range | 0~50/60Hz (0-400HZ for PMSM) |
MPPT efficiency | 99.6%, |
Ambient temperature range | G-type inverter with submersible pumps, and P type for general pumps. |
Solar pump control special performance | MPPT ( maximum power point tracking), CVT (constant voltage tracking), auto/manual operation, dry run protection, low stop frequency protection, minimum power input, motor maximum current protection, flow calculating, energy generated calculating. |
Protection function | Phase loss protection, phase short circuit protection , ground to phase circuit protection , input and output short circuit protection. Stall protection |
Protection degree | IP20, Air force cooling |
Running mode | MPPT , CVT, variable frequency mode |
Standard | CCC, CE, IEC |
