The machine is used to harvest corn kernels, change the cutting platform and harvest wheat, rice, sorghum, millet and other crops.
The machine can complete the operations of harvesting, threshing, separating, cleaning and collecting grain of corn (wheat, rice, sorghum and millet) at one time, and it is suitable for the plain and semi hilly areas.
Specifications for 5-row corn harvesting( separate grain from cob)
Model
4YZL-5
structure type(self-propelled)
separate grain from cob
Dimension
7400*3020*3450mm
Total weight
7140kg
Harvesting rows
5
working efficiency
0.6-1.4 hm2/h
fuel consumption per unit area
max. 35 kg/h m2
Rated power
129kw
working width
2930mm
Threshing drum type
Longitudinal axial flow
working speed
1.6-9.8 km/h
min. ground clearance
350mm
Grain bin
2000L
Features
(1). Using (3+1) gear mechanical transmission, walking hydraulic step-less speed change, easy to operate, more stable speed, can be applied to different field operations requirements.
(2). the plate type picking and cutting platform adopts the knife type pull stem roller + the picking board, and the ear and the straw are separated thoroughly without dropping the grain.
(3). the lifting and lowering of the cutting table and the discharging of the grain of the ear are all hydraulically operated, and the operation is flexible and convenient;
(4).The threshing drum adopts single longitudinal axial flow roller, Threshing and separating area is large, clean threshing , crushing rate is low, the cleaning device adopts double deck scale vibrating screen, The cleaning area is large, the grain loss and the impurity content is low.
(5).Equipped with domestic famous brand engine, high horsepower (175 horsepower), scientific and reasonable power matching, economical operation and environmental protection.
(6). It is convenient and quick to unload grain by using high spiral auger grain unloading pipe.
(7). It has the advantages of reasonable configuration, short body, low center of gravity, small turning radius, and shorter U-turn time.
Product Line
fRaw material
Cutting
Machining
Welding
Painting
Assembly-1
Assembly-2
Testing
Finished products
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
