Yumo NH1 125A Filler Closed Tube Type HRC Low Voltage Fuse Link
- Category: Fuses >>>
- Supplier: Yueqing,Ying's,Import,&,Export,Co.,Ltd.
Share on:
Product Overview
Description
Yumo NH1 125A Filler Closed Tube Type HRC Low Voltage Fuse Link
Features
According to IEC60269,DIN43620,GB13539 and CE Safety,Rohs CERTIFICATE
Rated voltage:AC500V/690V or DC 440V
Rated current:2A~1250A
Exception:Size 00 with DC 250V
Operating class:
gL/gG for cable and conductor protection
aM for motor protection
aR for semiconductor protection
Finely graduated selectivity
Rated breaking capacity:AC 120kA(Size 00:AC 50kA)
| Type | Rated current(A) | Dimension(MM) | Unit Weight(g) | |
| NT00C | 2,4,6,10 | A | 78 | 145 |
| R030C | ||||
| 16,20,25,32, | B | 49 | ||
| C | 15 | |||
| 36,40,50,63, | D | 21 | ||
| E | 52.5 | |||
| 80.100A | F | 6 | ||
| NT00 | 2,4,6,8,10,20,25, | A | 78 | 180 |
| B | 49 | |||
| RT16-00 | 32,36,40,50,63,80,100,125,160 | C | 15 | |
| D | 28.5 | |||
| E | 55.5 | |||
| F | 6 | |||
| NT0, RT16-0 | 4,6,10,16,20,25,32,36,40,50,63,80,100,125,160A | A | 122 | 240 |
