Product Description | Part Number | 3524695 | | Previous Version | 3591608, 3524598 | | OE number | 5000670624, 5000670625, 5000670626, MIDR-62045SB, 5000681178, 5000670512, 5000686372, 5000681665, 5000670721, 5000690607, 5000670624, 5000670626, 5000681178, 5000690606, 5000681117, 5000786471, 5000670627, 5000670720, 5000681269, 5000681664, 5000681082, 5000786041, 5000670625, 5000787416, 5000787415 | | Description | C290, R330, DG290, G290, DG320, FR1, DG290, C290, DG320, SB G29, SH C290 Truck, SB FR1 Bus | | CHRA | 3519065 NEW IN STOCK | | Turbo Model | H2C, H2C-8640AS/P22U3 | | Engine | MIDR062045 | | KW | 243/320 | | Displacement | 9840 ccm, 6 Cylinders | | Fuel | Diesel | | Angle α (compressor housing) | 135° | | Angle β (turbine housing) | 155° | | Bearing Housing | 3525199 NEW IN STOCK | | Turbine Wheel | 3522232 (Ind. 86. mm, Exd. 72. mm, 11 Blades) NEW IN STOCK | | Comp. Wheel | 3503304 (350330400) (6+6 Blades) NEW IN STOCK | | Back plate | 3762564/62564/167543 (1253300300) NEW IN STOCK | | Heat shield Number | 3529846 NEW IN STOCK | | Repair Kit | 3545653 (1152302750) NEW IN STOCK | | Gasket (turbine inlet) | 409123-0002 (310694)(Inox Steel) | | Gasket (turbine outlet) | 210239 (Stainless Steel) | | Gasket oil inlet | 210023 (147837, 210021, 215234, 52231586500) | | Gasket (oil outlet) | 210021 (148062, 311496) | | Substitute | 466200-0015 |
| |
