LPR System Parking Management Solution For South Korea
- Category: >>>
- Supplier: Shenzhen Thinkpark Technology Co. Ltd.
Share on (60716519190):
Product Overview
Description
Product Description
SXK-ALPR100 is a versatile license plate recognition (ALPR) system that can be applied in various business areas including intelligent traffic systems (ITS), car park and fleet management, traffic and road patrol, highway, toll, checkpoint, border security and surveillance. The system automatically detects, recognizes and verifies license plate, both alphanumeric and non-alphanumeric, of vehicles. SXK-ALPR100 has successfully recognized over 50 countries' license plates in multiple languages including English, Chinese, Korean, Japanese, Thai, Spanish, Portuguese, etc.
Features&Function
1) 2.0mega pixel SONY Exmor CMOS sensor, progressive scan , WDR, low illumination, high definition.
2) Embedded intelligent algorithms for best viewing license plate day and night.
3) ONVIF protocol,GB28181 protocol, compatible with main NVR manufacturer, Hikvision, Dahua, etc.
4) HLC(highlight compression) function, auto shift from daytime setting mode to night setting mode. Good anti-headlights night effect.
5) WDR adjust ,1-3 lanes surveillance.
6) Shutter speed adjustable: 6 traffic modes selectable: 30KM/H, 60KM/H, 90KM/H,120KM/H,150KM/H,180KM/H standard mode.
7) Easy setting: no need professionals, no need client software. Manual setting all the function on control board inside camera. Connect NVR or computer,playback video, pase and see license plates clearly.
8) Varifocal lens: f=622mm1.8InchLCDdisplaymenu.:LED luminance value, HLC intensity, AGC value, current traffic mode...ETC
9) 4PCSwhite bright lights.Color image at night. Night vision distance <20 M. Luminane add+ / decrease-, adjustable no matter in daytime or at night. Auto shift from daytime setting mode to night setting mode.
10) IP66, waterproof. . High quality double shield housing.Heater, FAN Option.
11) Support auto snapshot number plates when connection with inductive loops,etc trigger.snapshot JPG images store in TF card (max.32G) and/or FTP server. (TF card excluded).
12) Double front glasses to avoid light halo and spot when LED is ON.IR illuminator option, black & white image at night.
Technical Parameter
| Plate recognition rate: | Day>=95.9%; Night>=95%; |
| speed adjustable: | 0-100KM/H; |
| Output Information: | Car feature image; car plate image; Car plate number; Pass time; |
| Data interface mode: | 10/100M Ethernet TCp/IP; |
| Image Sensor: | 1/3'' CMOS |
| Effective pixels: | 1080P |
| Minimum illumination: | 0.1 Lux (standard) |
| Signal to noise ratio: | >50db; |
| Electronic shutter: | 1/1 to 1/10000s; |
| Best shooting range: | 3-10m; |
| Luminous frequency of light source: | 50HZ; |
| IP Protection: | IP 66; |
| Working Temperature: | -25℃~70℃; |
| Working Humidity: | <=90%; |
| Power Voltage: | DC 7-24V; |
| Housing Size: | 400*290*1600mm; |
| Interface type: | Define | Instruction |
| Input/ Output: | ALARM_IN 1+; ALARM_IN 1-; ALARM_IN 2+; ALARM_IN 2-; | 2 high or low level or switch volume input; |
| Input/ Output: | ALARM_OUT 1+; ALARM_OUT 1-; ALARM_OUT 2+; ALARM_OUT 2-; | 2 switch volume input; |
| Input/ Output: | RS485_A1; RS485_B1; | 485 port 1; |
| Input/ Output: | RS485_A2/RS232_T; RS485_B2/RS232_R; | 485 port 2 or 232 port; |
| Internet Interface: | RJ45 | 10M/100M adjustable; |
| Audio frequency: | AUDIO-IN; AUDIO_OUT; | Audio IN(MIC); Audio Out; |
| Reset: | Manual Reset; | Manually restore factory Settings; |
| Save: | TF Card | TF card (microSD card) |
Detailed Images
Automatic License Plate Recognition System:
