HZ T904 Automatic Tunnel Foam Car Washing Machine with Good After Sales Service

Machine Function

This car washing machine is suitable for the small and medium size vehicle to high pressure water washing, wax, drying, chassis cleaning and wax.

Machine Features

1. Main components are high reliability with long service life.

2. Automatic control and multi-function operation, such as washing, drying and wax.

3. Tunnel type structure is safe and good view. (Glass wall is optional)

4. High pressure water system clean the vehicle all direction.

5. Small side brushes for wheel cleaning and chassis cleaner.

6. Chinese foam & super soft brushes, impossible to scratch lacquer, each set could be used for about 100,000 car-times.

7. Dried by strong fans, to make the car dry rapidly.

8. Water recycling system optional to protect environment and save water.

 Technical date:

Machine size: 12800x4000x3200mm (L x W x H)
Washable car size: 1950x2000mm (L x W x H)
Conveyor speed: 5-6m/min
Washing capacity: 60-80 cars per hour
Water consumption: 150-200 liters per car
Power supply & consumption: 380V, 50Hz, 3Phase, 26Kw
Compress air supply: 0.8Mpa
configrtaion:4 side small brushes+4 side big brushes+1 top brush+2side dryer +2 top dryer+1 chassis wash
