Textile wool washing dewatering drying machine / wool dryer equipment
- Category: >>>
- Supplier: Zhengzhou Aslan Machinery Co. Ltd.
Share on (60717158670):
Product Overview
Description
Textile wool washing dewatering drying machine / wool dryer equipment
Machine working principle:
according to the principle of heat exchange. The machine make use of the exhausted heat by steam radiator and the suction fan suck in the air continuously, the produce a thermal cycling, which make the material in the drum turn over constantly, gradually drying.
Technical parameter:
Machine model | ASL-HGJ15 | ASL-HGJ30 | ASL-HGJ100 | ASL-HGJ120 |
Max capacity (kg) | 15 | 30 | 100 | 120 |
Drum dimension (mm) | 750*560 | 950*860 | 1320*1100 | 1500*1080 |
Drum speed (r/min) | 35 | 32 | 30 | 28 |
Steam pressure (Mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
Motor power (kw) | 0.75 | 1.1 | 2.2 | 2.2 |
Fan power (kw) | 0.75 | 1.1 | 1.5*2 | 1.5*2 |
Machine size (mm) | 700*1100*1340 | 1100*1450*1900 | 1500*1800*2360 | 1600*1800*2360 |
Weight (kg) | 313 | 396 | 672 | 875 |
Machine photo:
Packaging & Shipping
A conner of workship
Machine freight by truck or container. Container machine be fixed by steel wire, to make sure all of them not be damage by transport jolt.
About package we will use 1cm plywood standard export wooden box.
About documents
We can provided Telex release bill of loading or Original Bill of loading, Certificate of original. Other documents can be provided according to your requirement.
Our Services
About after sell service of our aslan machinery
Usually machine guarantee time is about 1 year. Within guarantee time. Machine breaking caused by machine itself design defect, we are responsible for it. We can provided free charge breaking part. If machine breaking caused by humane factor, user need take responsibility for it, we will provided technical support .
About goods shipping of our aslan machinery
We have long time working shipping forwarder. We can do our best to send machine to your port safe and sound. If your need, we can help you do custom clearance .
About payment term of our aslan machinery
Currently, in order to protect you and us rights. Both us in safe, hope we can do business in safe way .
L/C(>20000USD),Western Union,T/T(bank transfer),Escrow
which one is you want, we can discuss it .
About online Service of our aslan machinery
24 hours online to solve any problem. Your email will be reply within 12 hours. Your satisfy is our pursuit. Sincerely hope our cooperation .
Company Information
Business Philosophy
Quality is our life
Good cooperation starts from trust
Scope of Business
We specializes in processing machine export and import bussines. Our business scope ranges from food machines, agriculture machines to meat processing machine and so on.
A complete production line if you want, we also can provide.
For example, for potato processing machines, which include potato harvest machine, potato washing and peeling machine, potato sorting machine and package machine.
For meat processing machines include meat washer, meat chopper, meat bowl cutter, meat tumble and meat deboning machine, meatball making machine and so on.
Contact Me
If you are interested in our machines, please feel free contact us:
I will try my best to service you.
Looking forward our cooperation in near future.
