uk type Protector PRCD 1 gang13A switch protected socket outlets

Features

Latching Passive Type, No Need To Reset After Power OFF manually after Power OFF and ON.

Latching RCD (Sometimes called Passive) When the power is lost due to an earth fault, the RCD trips out and isolates the circuit it is protecting. Latching RCD’s do not trip during power cuts so they are great for fridges and freezers and also for protecting remote/unmanned areas.

This would also make them ideal for protecting some heating equipment set to “Frost Protection”, fish tanks, battery charging, and the protection of remote or unmanned areas.

Non-Latching RCD (Sometimes called Active) – When the power is lost due to earth fault or power cut, the RCD isolates the circuit that it is protecting and remains off until it is manually reset. A must for protecting circuits supplying rotating machinery or some heating apparatus for example.

Technical Data

♦ Rated Voltage:  240VAC

♦ Rated Current:  13A max

♦ Frequency:  50Hz

♦ Tripping current:  10mA & 30mA

♦ Maximum Tripping Time:  40mS

♦ Voltage Surge: 4K (100KHz Ring Wave)

♦ Endurance: 3000 Cycles min

♦ Hit-Pot Test: 2000V/1 Minute

♦ Approval: CE&BS

♦ Standard: BS7071 BS7288 and BS1363

♦ Body Material: PC

♦ Cable capacity:3X2.5mm2

♦ IP Rating:IP4X

♦ Dimension:86X86mm
