USA pdu 15a 125v 7 ways outlet metered function cabinet pdu
- Category: >>>
- Supplier: Ningbo Tuxin Communication Equipment Co. Ltd. [Zhejiang China]Ningbo
Share on (60718758272):
Product Overview
Description
USA pdu 15a 125v 7 ways outlet metered function cabinet pdu
| Product Parameter: | |||
| Input characteristics | Size | ||
| Rated input voltage: | 125VAC | Product size: | LXWXH=482.6X44.4X62mm (19 inch) |
| Cable specification: | H05VV-F3G 1.5mm^2 | Mounting length: | 482.6mm |
| Type of plug: | 5-15P | Test items: | |
| Cable length: | 2m | hi-pot test: | PASS |
| Max input current: | 10A | Grounding: | PASS |
| Output characteristics: | IR: | PASS | |
| Output quantity: | 6 ways | Product color& material: | |
| Rating output voltage: | 125VAC | Product color: | RAL9005(black) |
| Max output current: | 15A | Shell material: | Aluminum alloy |
| Max output power: | 3.5KW | Plastic flame retardant rating: | UL94V-0 grade |
| Functions: | Mounting: | ||
| Control: | Metered | Mounting method: | Horizontal installation |
| Protection: | master switch | Packing: | Standard export packing |
