30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel
30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel
30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel
30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel
30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel
30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel
30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel

30w,40w,50w,60w,70w,80w,100w poly solar panel ,manufacture and cheap price sunpower solar panel

Share on (60718826424):


Price:$9.00 - $10.00

Quantity:


Product Overview

Description


Product Specification


ELEC TRICAL CHARACTERISTICS AT STC














































































Nominal Power(Pmax)10W20W30W40W50W60W
Open circuit Voltage(Voc)21.76V23.12V24.48V23.12V21.76V21.76V
Short circuit current(Isc)0.58A1.09A1.54A2.17A2.88A3.46A
Voltage at Nominal Power(Vmp)18.24V19.38V20.52V19.38V18.24V18.24V
Circuit at Nominal Power(Imp)0.55A1.04A1.47A2.07A2.75A3.29A
Module Efficiency (%)20%20%20%20%20%20%
Operating Temperature -40℃ to+85℃
Maximum System Voltage1000VDC(IEC)/600VDC(UL)
Fire Resistance RatingType 1(in accordance with 1703)/Class C(IEC61730)
Maximum Series Fuse Rating15A
*STC:Irradiance1000W/m2,Cell temperature25℃,AM1.5,Power Tolerance 0~+3%
