Brand new ultrasonic lace machine roller made in China (60718883190)

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description


Brand new ultrasonic lace machine roller made in China










Technical parameter

Source power220V +/- 5V 50/60HZ 6A
Input power1500-2500(Can adjustable)
Output frequency20KHZ
Working speed0-20m/min
Roller sizeWidth:0-60mm Diameter:φ50-φ60mm
Dimension (L*W*H)1200*600*1200mm
Net weight90KG
Working temperature≤ 25℃







D334334943FFEC39EAA7D19997CCD12D



Basic components

1. New type PC intellectual ultrasonic generator;

2.20KHZ ultrasonic transducer unit;

3-Bottom mould fixed suspension structure;

4 .Single motor speed adjustment system;

5. Manual ( or pneumatic ) roller lifting system;

6. Double-barreled framework and heavy support board.

Characteristics

1.Built-in PC chips, multi-circuit ultrasonic protection system to make the machine run safely;

2.Strong ultrasonic power with three adjustable gears (maximum, medium and minimum),meets the welding requirements of different materials and thicknesses;

3.The performance of the machine reaches international level with autom­atic frequency tracking system and ultrasonic soft-starting technology;

4.Variety of roller patterns,other roller designs available according to cust­omer requirements;

5.Four times faster then sewing machines.minimal operator training required.

Functions

1.Trimming:Straight or curvilinear edge cutting and edge treatment for me­lting,so smooth.no rough edges;

2.Sealing:Two or more layers of fabric stitched together without thread re­placing the sewin needles.good welding strength;

3.Hole making:Cut out the various patterns of holes,and treatment of side melting;

4.Slitting:Single or more cutting of the material at the same time.and treat­ment of side melting without burr;

5. Forming:Simultaneous cutting,sealing and embossing to make production in one time.

Suitable materials

All kinds of artificial leather and fabric, non woven fabric,spun-bonded cotton, thermoplastic film, chemical plastic piece.etc.

Applications

Lace clothing,ribbon .decoration products,handkerchief,tablecloth,curtain,bedspresd,pillowcase,quilt cover,tent,raincoat,disposable operating coat and hat,disposable mask.non-woven fabric cloth and so on.







leather ultrasonic lace sewing cutting machine

Changzhou yana electronic equipment co., LTD., specializing in the production of computer intelligent ultrasonic lace machine, ultrasonic non-woven bag making machine and other accessories Ultrasonic and all kinds of garment machinery and special equipment.

The company to pursue science and technology leading, customer-orientated business philosophy, over the years to ultrasound equipment research and development work.Currently has a ultrasonic lace machine, pressure machine, spot welding machine, wireless sewing machine, bag making machine, ultrasonic sewing machine, ultrasonic waveHeat sealing machine and so on many kinds of utility equipment. Wherein, ultrasonic lace machine for its wide application scope, product characteristics, praised by many customers at home and abroadLove. Widely used in clothing pieces, napkins, tablecloths, curtains, window cover, craft jewelry, headdress hairpin, clothing accessories and other fieldsDomain.

The company perennial spot, according to the special requirements of customers customized eq­uipment. At the same time, to undertake a variety of lace processing, collar, clothing, cut pieces of red flower business. Company to a strong product development ability, perfect quality management system, many customers at home and abroad to provide the production of sophisticated, superior performance of pro­duction equipment. Products are exported to Hongkong, Singapore, Indonesia, Japan, Italy, Vietnam, Russia, South Africa, Turkey, Taiwan, France, Iran, India and other countries and regions, praised by customers. . Integrity and pragmatic, market-oriented, pay attention to quality is our business purpose; innova­tion and development, and continuously exceed our goals. Welcome customers at home and abroad and we have established long-term friendly relations of cooperation.



quilting machinery

Q1. Are you trading company or manufacturer ?

A: Yes, We are factory, all machine is made by ourself and we can provide customize service according to your requirement.



Q2. How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.



Q3. What about your warranty?

A: Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(not including man made).



Q4. What is your terms of payment ?

A: T/T 30% as deposit,and 70% before delivery.We'll show you the photos of the products and packages before you pay the balance.
