Factory Price 4.3 inch Monitor High definition Screen CCTV Camera Tester
- Category: CCTV Accessories >>>
- Supplier: Shenzhen Ccdcam Technology Co. Limited
Share on (60719062254):
Product Overview
Description
Hot Sale 4.3 inch TFT LCD High-definition Screen HD Camera Tester
Product Description
| Model | ET-IV7 | ET-IV7A | ET-IV7T | ET-IV7M | ET-IV7S |
| HD Test cctv hd camera tester | |||||
| HD video signal | Base type CVBS@D1 | 2IN1 CVBS@D1 AHD@720P/1080P | 2IN1 CVBS@D1 TVI@720P/1080P | 3IN1 CVBS@D1 AHD/TVI@720P/1080P | 4IN1 CVBS@D1 AHD/TVI/CVI@720P/1080P |
| Resolution | D1 | D1,720P, 1080P | |||
| SD signal Format | NTSC ,PAL | ||||
| Signal Level | 1Vpp | ||||
| Power output | Temporary power output 12V 1A DC,USBX1 5V1A output | ||||
| Video test | |||||
| Video System | NTSC/PAL Automatically recognize | ||||
| Video level | 1VPP | ||||
| Display screen | 4.3-inch LCD 480 * RGB * 272 (QVGA) resolution, 64K color | ||||
| Screen adjustment | Video display brightness, contrast, color saturation adjustable, LCD backlight brightness adjustable | ||||
| Video input | 1 channel BNC Video IN | ||||
| Audio test cctv hd camera tester | |||||
| Audio test | Input audio signal, and played on the internal speaker | ||||
| Power supply | |||||
| External power supply | DC 5V | ||||
| Battery-powered | Built-in 3.7V li-polymer battery, Capacity 2600mAh | ||||
| Charge | Charge time 3-4 hours Battery power time 8 hours | ||||
| Power saving features | Low power consumption, automatic power off, Real-time display of battery level | ||||
| System settings cctv hd camera tester | |||||
| Language settings | Chinese, English user selectable | ||||
| Auto power off | Disable / 5-60 minutes | ||||
| Cable test cctv hd camera tester | |||||
| cable test | Test any two or more wire cable Display connect sequence and remote number | ||||
| LED Light | 1*35lm LED light | ||||
| Working environment and Specifications | -20C~+70C,30%~90% Rh | ||||
- Note:this product with 5 type model, it can input different vedio signal(AHD/CVI/TVI/CVBS),
it can use for max 1080P HD signal input (Base type only support CVBS Analog camera input max D1).
Please confirm your camera can be Connect,before you Buy.
if you want to test 3MP and 4MP camera ,please stop to order this product.
- HD Analog camera test cctv hd camera tester
- 4.3" high image resolution monitor
- support 12V DC output and USB 5V output (Mobile Phone Power Supply)
- Support PTZ control tes ting and cable testing
Our Services
1. Good quality products and low factory direct price
2. Free technical support and professional advice,timely communication and after-sale service
3. 24-hour aging process, 2-year warranty, CE/FCC/RoHS compliant
4. OEM/ODM service
a) Customized camera housing
b) Print logo on the camera
c) Any your idea on camera we can help you design and put it into production
5. Fast delivery, 3-7 days for production
6. Accept paypal, T/T, western union payment
7. Delivery by DHL/EMS/FedEx, by air or by sea etc
Company Information
Contact Person
Any info. want to know,pls do not hesitate to contact me.
Skype:ccdcamp
QQ Number:2394606613
Mobile/Whatsapp:0086-18170601665
cctv hd camera tester cctv hd camera tester cctv hd camera tester cctv hd camera tester
