High Performance Manual Hot Stamping Foil Film Tape Log Roll Cutting Machine
- Category: >>>
- Supplier: Shenzhen Micheda Industrial Co. Ltd.
Share on (60719475946):
Product Overview
Description
High Performance Manual Hot Stamping Foil Film Tape Log Roll Cutting Machine
| Machine Name | High Performance Manual Hot Stamping Foil Film Tape Log Roll Cutting Machine |
| Machine Size | 1750mm*2100mm*1870mm |
| Weight | 1450kg |
| Power | 4.5kw |
| Power supply | Three-phase five-wire system(380v ×3+center zero line+ ground line),50HZ |
| Wiring | 2.5mm2 ×3 + 1.5mm2×2 20A single-phase with leakage circuit breaker |
| Jumbo Roll size | The inner diameter of Jumbo roll is 6", The maximum diameter of Jumbo Roll is D600mm; Wide is 1100mm |
| Finished roll size | The inner diameter is 1" & 1/2", minimum width 22mm, maximum diameter D120mm |
| Ribbon thickness | 0.0045~0.035mm |
| The max cutting speed | 150m/min |
| Tension System | Servo |
| Head-end ribbon packaging | Semi-automatic |
| Air Power | 0.6MPa, 0.5L/min: Joint Pipe Bore: D10mm |
| Electronic Control System | Mitsubishi |
