ezcap295 1080P HD Capture Pro Save Video to HDD Support Playback Watermark Schedule bitrate resolution Splite/un splite Steaming

Product Overview

Description

HD Video Capture Pro



With this ezcap295 HD Video Capture Pro, you can capture up to 1080P video from HDMI ,Ypbpr (component) or composite port, such as blue ray, set-top-box, computer, game box, VHS, etc. And you can playback the record movie directly.



Ezcap295 has record and playback two function in one device, use remote controller to set to playback mode. You can also set schedule recording, set recording quality, set split recording file or not.

Features/ports and buttons:





1.PC/DC—DC 5V power supply,or connect to PC.



2. HDMI IN—HDMI input.



3. AV / YPBPR—Ypbpr component or composite input through adapter cable



4. MIC IN—For connect a microphone and record voice comments when play game.



5. LINE OUT—Audio output.



6. HDMI OUT—HDMI output, so can connect to monitor to pass through display the input video.



7. HOST—Plug a USB flash (or USB HDD) to save record video.



8. Record button  —Press button to record/stop record.

Remote controller:



Record:  Directly Save 1080P HD Video into USB Sticker or HDD.

1)Schedule record:

2)Set the recording video quality & split:



Press “MENU” of remote controller, enter to following menu, “clock” to set the time of system, “REC” is schedule (same function as above), “REC Video Quality” you can set to High, Middle, Low, to set the recording video bit rate to 16, 10, 4Mps

The “RECORD_FILE” you can set to SPLIT or NO_SPLIT(NTFS), to SPLIT means will cut the record file to 2GB each both in FAT and NTFS storage.  NO_SPLIT(NTFS) means will cut the record file to 2GV each in FAT storage, but will save in one whole file in NTFS storage.



3)Personal recording settings: Snapshot, recording bitrate, watermark, Mute/volume adjust, MicroPhone Mute/adjust, Aspect Ratio...



4)With Playback function, allow you playback the recorded video directly, and delete the files you want. Works with OBS on your computer for live video streaming.





Specifications:

Connections
Interface			USB 2.0 Host
Video Input			Digital: HDMI
			Analog: Component Video, Composite Video
Audio Input			Digital: HDMI
			Analog: 3.5mm Microphone In. Analog L/R in
Video Output			Digital: HDMI (Pass-through from HDMI or Component or Composite Input)
Audio Output			Digital: HDMI (Pass-through from HDMI or RCA L/R Input)
			Analog: 3.5mm Stereo (Pass-through from HDMI or RCA L/R Input)
Applicable Connections with Game Consoles
HDMI			Industry HD camera, HD Medical endoscope, TV, gameplay, etc
Component			TV, gameplay, etc
Composite			Industry camera, Medical endoscope, TV, gameplay, etc
Hardware Extra
Codec			Hardware H.264 encoder
User Interface			Record button, mode switch button.
			LED indicator for working status.
			infrared receiver
Dimensions			142(L) × 73(W) × 26(H) mm.
Weight			110g
Package Contents
Device			ezcap295 HD Video Capture Pro
Others			DC adaptor, remote controller, AV cable, Manual
Standards
Storage Media			USB Flash Disk, Portable Hard Disk
			Max Capacity: USB / 2T
			Note: The exFAT format is not supported.
Resolution			Input / Pass-through:                                                                                             720 x 480 (60p), 720 x 576 (50p), 1280 x 720p (50p), 1280 x 720p(60p), 1920 x 1080 (50i), 1920 x 1080 (60i), 1920 x 1080 (24p), 1920 x 1080 (25p), 1920 x 1080 (30p), 1920 x 1080 (50p), 1920 x 1080 (60p)
			Capture:                                                                                                               1280 x 720p(60p), 1366*768 (60p), 1920 x 1080 (30p)
Record Format			Video: MP4, Audio: AAC Stereo
Record Quality			Max: 16Mbps@1080P 30fps
Record File			Max: 2GB / Per File, With RTC (Real Time Clock)
Record Place			Max: 140MB / Minute, 8.4GB / Hour
Power Supply			USB DC 5V / 2A
