Road paint high pressure water remove cleaning machine
Road paint high pressure water remove cleaning machine
Road paint high pressure water remove cleaning machine
Road paint high pressure water remove cleaning machine

Road paint high pressure water remove cleaning machine

Share on (60720944773):


Price:RUB 7,807,290.00 - RUB 11,710,935.00

Quantity:


Product Overview

Description

Asphalt road marking line removal machine Application

1.JL-PHQ alloy knife road marking remover is specialized for clearing away the broken, stained and wrong marking lines.
2. Alloy knife
3. Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble.



Asphalt road marking line removal machine Technical Data

Model

JL-PHQ

Engine

Kohler or Briggs 10.5 HP gasoline engine

Removal grinding head

Tungalloy cutter, 24 teeth for thermoplastic marking lines, 48 teeth for cold paint marking lines

Removal depth control

Accurate pitch depth adjuster

Removal pressure control

Dial instruction pressure adjuster

Clutch protective device

Automatic clutch equipment

Dust collector joint

Φ 76 mm

Operation method

Pull, push, wave

Removal width

180 mm - 620 mm

Dimensions (L*W*H)

1240 mm × 780 mm × 1100 mm

Weight

230 kg

Optional system

Dust collector and roll booster



Removal machine.jpg


 .jpg


Old Road Marking Paint Removal Machine Features

Removal cutter: Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble.
Depth adjuster:  Fixed with depth adjuster equipment, can accurately adjust and fix depth according to the needs.
Pressure adjuster:  According to the conditions of road surface and different kinds of paint, the removal pressure can be adjusted.
Protective device: Automatic clutch makes the cutter automatic clutch with removal shaft according to the engine speed and the conditions of road surface, which makes sure the high quality removal, fewer damages and extends service life.
Emergency stop device: Equipped with emergency stop switch, which can stop the machine in short time.
Parking device: Convenient foot control parking system makes the machine in safety condition in any time.
Operation: Forward, back off, left or right operated freely.

Chassis: A firm welded frame, whose surface has been chrome-plated or high temperature treatment;

the four-wheel structure makes the whole machine work more stable, and operation more convenient.

Features

Removal cutter: Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble.
Depth adjuster:  Fixed with depth adjuster equipment, can accurately adjust and fix depth according to the needs.
Pressure adjuster:  According to the conditions of road surface and different kinds of paint, the removal pressure can be adjusted.
Protective device: Automatic clutch makes the cutter automatic clutch with removal shaft according to the engine speed and the conditions of road surface, which makes sure the high quality removal, fewer damages and extends service life.
Emergency stop device: Equipped with emergency stop switch, which can stop the machine in short time.
Parking device: Convenient foot control parking system makes the machine in safety condition in any time.
Operation: Forward, back off, left or right operated freely.

Chassis: A firm welded frame, whose surface has been chrome-plated or high temperature treatment;

the four-wheel structure makes the whole machine work more stable, and operation more convenient.

Features

Removal cutter: Imported tungalloy cutter is hard and high speed rotating, with long service life, and easy to assemble.
Depth adjuster:  Fixed with depth adjuster equipment, can accurately adjust and fix depth according to the needs.
Pressure adjuster:  According to the conditions of road surface and different kinds of paint, the removal pressure can be adjusted.
Protective device: Automatic clutch makes the cutter automatic clutch with removal shaft according to the engine speed and the conditions of road surface, which makes sure the high quality removal, fewer damages and extends service life.
Emergency stop device: Equipped with emergency stop switch, which can stop the machine in short time.
Parking device: Convenient foot control parking system makes the machine in safety condition in any time.
Operation: Forward, back off, left or right operated freely.

Chassis: A firm welded frame, whose surface has been chrome-plated or high temperature treatment;

the four-wheel structure makes the whole machine work more stable, and operation more convenient.

road marking.jpg



Thermoplastic Road Marking Applicator.jpg
