Model:MYA

Technical parameters F-20 | |
Basic parameter | |
Body size:L×W×H mm | 2040*1220*1565 |
Wheelbase mm | 1460 |
Tread(Front/rear)mm | 990/990mm |
Min. ground clearance mm | 140 |
Full mass kg | 580 |
Seats | 2 |
Performance parameters | |
Economic power consumption 100KW/H | 8 |
Max speed KM/H (full load) | 40 |
Climbing capacity % (full load) | 20 |
Range (speed 40KM/H) | 150KM |
Power parameters | |
Motor type | Brush-less DC motor |
Rated motor power kw | 4 |
Rated motor voltage V | 60 |
Battery type | Maintenance free lead-acid |
Battery capacity | 12V 120Ah |
Battery cell | 5 |
Charger type | Car charger |
Charger voltage V | 110-220 |
Charge time Hour | 8-10 |
Transmission system | |
Transmission system | Automatic |
Gear type | Automatic control |
Differential case | Yes |
Chassis | |
Drive type | Rear wheel |
front suspenssion | Macpherson struts |
Rear suspenssion | Integral damping |
Body type | Unitary construction |
Brake type(front/rear) | Disc/disc |
Parking type | Handbrake |
Wheel size | 145/70R12 |
Wheel type | Alloy |
