home inverter ups High Frequency Home Inverter , Cheap Power Inverter

Product Overview

Description

home inverter ups High Frequency Home Inverter , Cheap Power Inverter

Main Features
1.Micro Processsor Control
2.Low battery protection
3.Isolated output
4.Selectable charge current
5.Automatic and silient operation
6.Automatic Line-to-Battery Switch over
7.Application for Fan, light ,TV and office Appliances
8.Automatic charge while AC recovery(off model charging)
9.Multi-function LED&LCD Display and buzzer alarms.
10.Over load,short circuit protection
11.Cool start
12.Rack and Tower design
13.Compatibility with generators
14.Battery Polarity Protection optional
15.Intelligent Automatic Charging Technology
16.User selectable for accepting wider input voltage
17High Efficient DC-to-AC conversion,minimizing energy loss



MODEL	1000VA	1500VA	2400VA
SPECIFICATION
DC INPUT
Input Voltage(Vdc)	12Vdc	12Vdc	24Vdc
Input DC Range(Vdc)	10-16Vdc		20-32Vdc
AC Bypass in “on/off” switch off mode
Nominal Input Voltage(Vac)	220/230/240Vac
Input AC Range(Vac)	170-280Vac(Narrow Range) or 90-280Vac (Wide Range)
Input Frequency(Hz)	50/60 Hz
Bypass Output Voltage(Vac)	SAME AS INPUT AC
Bypass Output Frequency	SAME AS INPUT Frequency
Charge Current(A)	15-20A±2A (Selectable)		15A±1A
Charge Bulk Voltage	14.4±0.2Vdc		28.8±0.4Vdc
Charge Floating Voltage(V)	13.75±0.2Vdc		27.4±0.4Vdc
Over Charge Protection	≥16±0.4Vdc, Fault, Buzzer alarm		≥32±0.8Vdc, Fault, Buzzer alarm
AC  Efficiency	>95% ( Rated R load, battery full charged )
Transfer Time(AC to DC)(ms)	15-20ms typical(narrow range); 40ms max(wide range)
Bypass Transfer time(ms)	≤5ms
AC OUTPUT (INVERTER)
Capacity(VA)	1000VA	1500VA	2400VA
Output Power(W)	700W	900W	1440W
Output Voltage	230Vac
Output Frequency	50/60Hz
Output Current(A)	4.5/3.2A	6.8/4.1A	10.8/6.4A
Voltage Precision(VAC)	230±10%
Frequency Precision	50/60Hz±0.2Hz
Output Voltage Waveform	modified sine wave
Inverter Efficiency	>83%	>85%	>86%
Over load capacity	>110% rated R load,60s later shut offer; >150%rated R load, immediately fault
LCD+LED Display	Output Voltage;Load Capacity;Battery Capacity; Line Mode;Battery Mode;Fault Mode
PROTECTION
Protection	overload/ short circuit protection
	Overcharge , discharge protection
AMBIENT
Noise(dB)	≤40dB (1 meter)
Temperature	-20~45°C
Humidity	0~95% ( no condensation)
Sea Level(m)	≤1500m
DIMENSION
Package L×W×H(mm)	663*378*588mm( 10pcs in one carton)
GW. Weight(Kg) /Carton	29	32	32
