Features:
1. Large 320*240 dots highlighted LCD.
2. Powerful functions like Photometric measurement, Quantitative measurement, Kinetics, Spectrum scan, DNA\\Protein test, multi-wavelength test, etc
3. The real double beam metering system, with advanced circuit measurement and control system, make the instrument with high reliability and low noise.
4. The USB port can be used for data transfer and storage.
5. Socket type deuterium and tungsten lamp can make lamps switching without optics debugging and easy to be replaced.
6. Large sample chamber can accommodate 5-100mm cuvettes of all kinds..
7. Extensive accessories are optional, such as auto 8-cell holder, film holder, tube rack, peltier/sipper system, 21 CFR compliant software, etc.
Specification
Model | UV1900 | UV1901 | UV1901S | ||
Optical System | Double Beam, Grating 1200 lines/mm | Single Beam, Grating 1200 lines/mm | |||
Wavelength Range | 190-1100 nm | 190-1100 nm | |||
Spectral Bandwidth | 2 nm | 1 nm | 0.5/1/2/4/5 nm | ||
Wavelength Accuracy | ±0.1nm@656.1nm, ±0.3nm@all | ||||
Wavelength Repeatability | 0.1nm | ||||
Photometric Accuracy | ±0.3%T(0~100%T) | ||||
Photometric Repeatability | 0.1%T(0~100%T) | ||||
Photometric Range | 0-200%T, -0.3~3A, 0-9999C | 0-200%T, -0.3~3A, 0-9999C | |||
Stray light | 0.05%T@220nm,360nm | ||||
Stability | ±0.0003A/h @500 nm | ||||
Baseline Flatness | ±0.0002A | ±0.001A | |||
Noise | 0.0005A@500nm | ||||
Work Mode | T, A, C, E | ||||
Scanning Speed | Hi, Med, Low (Max. 3000nm/min) | ||||
Wavelength Setting | Auto | ||||
Display | 320*240 LCD | ||||
Light Source | Imported Deuterium &Tungsten lamp | Deuterium &Tungsten lamp | |||
Detector | Imported Silicon Photodiode | ||||
Cuvette Holder | 10mm single hole cell holder | ||||
Output | USB port&Parallel port(Printer) | ||||
Power | AC 220V/50Hz; AC 110V/60Hz | ||||
Shipping Size | 810*660*390mm | 880*690*520mm | |||
Gross Weight | 27 kg | 45 kg | |||
Standard Accessaries | 10mm glass cuvette x 4, 10mm quartz cuvette x 2, Power cord, User's Manual , PC software | ||||
Button Panel
10mm single hole cell holder
RS232,and your company name can be shown on the nameplate
User's Manual
PC Software is optional,If buy software,we can send computer wire.
10mm glass cuvette x 4, 10mm quartz cuvette x 2 (UV)
Thermal Printer is optional
