innovative reverse osmosis water filter replacement seawater reverse osmosis
- Category: >>>
- Supplier: Tianjin Tian Gong New Material Technology Co. Ltd.
Share on (60722524302):
Product Overview
Description
Product Description
innovative reverse osmosis water filter replacement seawater reverse osmosis
Product advantage
1. SLE Series Product Performance Stability.
2. SLE Series is dry membrane elements, so it is easy to transport and storage time extend.
3. SLE Series be used for Rural and Urban tap-water or low salinity water due to it’s High Stable rejection and low pressure Advantage.
RO Membrane Performance
Model | Performace | |||
Stable Rejection /% | Average permeate flux /gpd(m3/d) | Recovery /% | ||
(Sapstone) Low Pressure domestic/commercial membrane element | SLE-1810-50 | 97.0 | 50(0.20) | 20 |
SLE-1812-50 | 97.0 | 50(0.20) | ||
SLE-1812-75 | 96.5 | 75(0.28) | ||
SLE-2012-100 | 96.0 | 100(0.40) | ||
Testing Conditions: |
| |||
Testing Concentration(NaCl) | 250 mg/L | |||
Testing Pressure | 60 psi(0.4 MPa) | |||
Temperature of Testing Solution | 25℃ | |||
pH value of testing solution | 7.5 | |||
Operation Limits and Conditions: | ||||
Membrane Type | Polyamide Thin-film Composite | |||
Max. Working Pressure | 300 psi(2.07 MPa) | |||
Max. Inflow Temperature | 45℃ | |||
Max. Inflow SDI15 | 5 | |||
Residual Chlorine Concentration of Feed Water | <0.1 mg/L | |||
PH Range of Feed Water During Continuous Operation | 3~10 | |||
PH Range of Feed Water During Chemical Cleaning | 2~12 | |||
Max. Pressure Drop of Single Membrane Element | 10 psi(0.07 MPa) | |||
Measurement of membrane element
Model | Size/mm(inch) | ||||
A | B | C | D | E | |
1810 | 256.0(10.1) | 44.5(1.75) | 17.0(0.67) | 25.0(0.98) | 15.0(0.59) |
1812 | 298.0(11.7) | 44.5(1.75) | 17.0(0.67) | 21.0(0.83) | 21.0(0.83) |
2012 | 298.0(11.7) | 48.2(1.9) | 17.0(0.67) | 21.0(0.83) | 21.0(0.83) |
Company Information
Tianjin Kung ta materials technology co., ltd. affiliated with Tianjin Jingwu Industrial Technology Research Institute and Tianjin Polytechnic University. Membrane separation technology as the core. Specialized in R&D, production and selling. Now our mainly products are reverse osmosis membrane flatsheet and RO membrane elements for residential, commercial and industrial.
Our president Wangwei is professor of Memebrane technology and teaching in Tianjin Polytechnic University Material institute. So our R&D Team is very strong.
Tianjin Polytechnic University State Key Laboratory of Separation Membrane and Membrane Processes ro membrane team in the antimicrobial anti-fouling reverse osmosis membrane
preparation technology has made important progress in their preparation of reverse osmosis
membranes in the presence of organic pollutants, inorganic pollutants and microorganisms Under all showed good anti-pollution, and the preparation method is simple, mild conditions, advantages of
high efficiency and economy.
During 2017, we have attended Chennai Water Expo. During 2018, we will on the ASIAWATER Malaysia. Now we have customers from Australia, Pakistan, India, Turkey, Russia, Sri Lanka etc.
Look forward to be your long-term and friendly supplier.
Packaging & Shipping
Why choose us
1. Adanvced Automatic production line.
2. Stable and large-scale produce capacity.
3. Strong R&D Team.
4. customize service provided as customer's required.
Our products use the most advanced technology, perfect technology, filtration precision is more accurate, membrane element removable replacement, long service life, high cost performance. And cartridge is the food grade material , pollution-free, non-toxic health!
