Hot! AFPMG Axial flux coreless low speed permanent magnet generator 300W 1kw 3kw 5kw 10kw 50rpm

Product Overview

Description



TGET380-0.3kW-50R design for 0.5-1kw vertical axis wind turbine; gasoline generators; hydroelectric generator.









Our disc coreless PMG have advantage in lowRated speed, Low starting wind speed, Small volume, Energy Small, Light weight, Compact structure, High efficiency etc.



1. Coreless, anhysteresis, slotless, have low starting torque.



2. No iron loss, have high efficiency



3. Adopt unique coreless precision winding technology design precision coil



4. Adopt the rare earth permanent magnet, which is multiple, mean gap, high power density and high output power.



5. Low speed direct driving, no torque fluctuations



6. Compact structure, high ratio of power to volume



7. No iron loss, low calorific value, small temperature rise



8. Simple structure, easy to install



9. The brushless structure, free maintenance























































1 year warranty for PMG generator.



We provide free maintenance during warranty if our products have problem; Will always give good warm after sales service to clients in time.
