Single Wire Coil Spiral Forming Making Binding Machine For Books
Product Description
Description:
HB-400PFBSingle Wire Coil Spiral Forming Making Binding Machine For Books.this machine is an automatic machine that combining paper/cover punching, single spiral forming and binding function. We are the first and only one whom design and manufacture this machine in China. So we have many patents of this machine.
High speed and stable, only need 1-2 person to opetate and very easy to adjust.
Highly improve efficiency and save cost.
Feature:
1. Automatic feeding, paper/cover punching single spiral forming and binding in one machine;
2. Only need 1-2 person to operate;
3. High quality mould, can punch 6mm for one time. And can choose punching times
form one to five times.
4. Automatic oil delivery system, two working sides of punching mould. Can be
changed in a very short time and long lift time than normal mould;
5. Can finish the product even though the cover is bigger than the inner sheets;
6. Punching holes automatic positioning fuction, make sure the binding will be
smoothly.
7. Automatic alarm and display function, engineer can act promptly.
Modle
HB-400PFB
Working speed
800-1500books/hr
Punching thickness(one-time)
1-6mm
Max. book size
400mm(punched side)*420mm
Min. book size
100mm(punched side)*140mm
Max. punching thickness
1-6mm
Max times of punching for one book
5 times
Max. book size for feeding belt
400mm*400mm
Size of single spiral wire
1/4"-5/8"
Pitch
4:1, 3:1, 6mm, 8mm
Width of paper for binding
100-400mm
Air pressure
0.7-0.8Mpa
Net weight
1250kg
Machine dimension
4000*2500*1600mm
Application:
DONGGUAN HENGBO BINDING MACHINERY CO.,LTD
