Food grade multi bag filters used in white sugar water filtration industry

Bag filters are particularly useful for filtering large volumes or high viscosity liquids, which are constructed of filter housing, filter bags, internal cage to support bags, positive sealing arrangement.

Main advantages

01.Small probability for side-bag leakage , which effectively guarantee the filtering quality.

02.Bag type filter can bear greater working pressure, it is of small pressure loss,low operation cost and obvious energy  saving .

03.Accuracy of filtration bag increased continuously, it could reach 0.5 μm at most.

04.Bag type filter large handling capacity, small volume, containing a large quantity of pollutants.

05.Based on the working principle and structure of Bag type filtering system,which is convenient to replace the filter bag and without cleaning,and time saving and labor saving.

06.Filtration bag could be use repeated after cleaning to save cost.

07.bag filter application scope is broad, with flexible operation and multiple installation .

Welcome to inquiry more detail .

Email:lyy(at)tsjmlc.com  Whatsapp:+86 18356516590

Specifications





Technical parameters	Design pressure: 0.96MPa 30min
	Maximum working pressure:0.60MPa
	Surface smoothness:Ra≤0.2
	Design flow rate:Ra≤0.2
	Inlet&outlet type thread or flange
	Type:single bag & multi bag filter housing
Designed for bag filtration system	Different kinds of bag support baskets to fit for
	wide range of filter bags
Complete stainless steel structure	Made of 100% SUS304, SUS316L, PP
Easy to clean	Surface is mechanical polished or sand blasting  passivation.
	dished end to aid clean down



Specifications for single bag filter housing

No.	Size	Diameter	Length	inlet&outlet	Filter bag	Flow rate
	Code	(mm)	(mm)		size	(m/h)
1	BJD1	220	550	2" thread, clamp, flange	1	20
2	BJD2	220	950	2" thread, clamp, flange	2	40
3	BJD4	130	650	1" thread, clamp, flange	4	10



Specifications for multi bag filter housing

No.	Size	Diameter	Length	inlet&outlet	Filter bag	Flow rate
	Code	(mm)	(mm)		size	(m/h)
1	BJD2-2	400	1600	3" thread, clamp, flange	2*2	80
2	BJD2-3	500	1600	3" thread, clamp, flange	2*3	120
3	BJD2-4	550	1600	4" clamp, flange	2*4	160
4	BJD2-5	600	1600	4" clamp, flange	2*%	200



Ordering Guide

PRODUCT	Bag Size	Bag Q'ty	Inlet/Outlet		Connection	Surface	Materials
BJD	1 -#1 bag	01 - Single	A- side in and side out		K-coupling	S- sand blasting	304
	2 - #2 bag	02 - Two	B- side in and bottom out		F-bolt	T- polished	316L
	3 - #3 bag	03 - Three	C- bottom in and bottom out		S- thread		PP
	4 - #4 bag	04 - Four	D- top in and bottom out		How to order ?-example
	5 - #5 bag	06 - Six			Bag size: #1;  Bag Q'ty: Single
	6 - #6 bag	08 - Eight			Inlet/outlet: side in and side out
	7 - #7 bag	12 - Twelve			Connection: coupling
	X - other size				Surface: sand blasting
					Material: SUS304
					Selection code is: BJD101AKS304





Operating Conditions(Bag Filter):

Max.Operating Pressure: 6 bar(87psi) ,  10.34bar(150psi)

Max.Operating Temperature: 120°C

Applications(bag filter housing eaton replacement):

Processing Chemicals	Paints,Inks,Coolants
Oils,Edible Oils, Vegetable Oils	Pharmaceuticals
Sugar Syrup	Cleaning Fluids
