MF HF GMDSS DSC SSB MARINE RADIO

Product Overview

Description

 MARINE MF HF RADIO

Brief introduction:	Model Number:		WT-B150
	Application Area:		WT-B150 is an important part of GMDSS system, which is adopted by the most advanced software radio technology and digital RF technology; it provides strong performances of receiving, transmission and operation and is fully compliant with the standards of IEC 61097-9, IEC 493-13 and other international standards. Besides, WT-B150 provides rich extended functions and interface.
	Certificate:		COSPAS, CCS,and ZY,meeting with standard of IMO/IEC
Function:	WT-B150 and its derivative products are used in variety ships. According to international maritime rules, the ships working in area of A2 to A4 must install this device. Besides, its derivative products can be used by land users as required.
Feature:	1.Convenient installation for users by the separated design of control unit and main unit.
	2.Three Operating Modes of SSB, AM and digital DSC
	3.One-click answer and forwarding of distress alarm and help signal
	4.SQL function.
	5.Fully compliant with the standards of IMO relevant to Digital selective-calling system
	6.Six simultaneously distress channel on duty, six routine scan channel on duty, and one SSB fixed frequency channel on duty.
	7.Automatic calibration function of clock frequency offset and excellent performance of frequency error.
	8.Internal and external switch for GPS
	9.Desktop installation and embedded installation
	10.The function of remote software upgrade
	11.The function of Chinese or English sms transceiver(Optional)
	12.Analog and digital communication of SSB. (Optional)
	13.Voice recording function of communication. (Optional)
Specification	1. MAIN UNIT:
	Frequency range: 1.6MHz~ 30MHz (transmitting), 0.5MHz~ 30MHz (receiving) .
	Frequency stability: ±10Hz
	Modulation type: SSB, DSC, AM
	Operating temperature range: -15℃~ 55℃
	Power requirement: 24V DC+30%/-10%
	Protection function: overvoltage, under-voltage, over-current, reverse, high VSWR protection.
	External interface: RS422, LAN and USB2.0.
	2.Transmitter:
	Output power: 200W/150W/100W
	Sideband suppression: ≤-60dBc
	Carrier suppression: ≤-60dBc
	Clutter suppression: ≤-60dBc
	Three order inter-modulation: ≤-28dBc
	3.Receiver
	Sensitivity: ≤11dBuV(SINAD=20dB)
	Audio Output Power: 4W/8Ω
	Audio Frequency Response:350Hz~2700Hz, <= 2dB
	AGC: ≥100dBc



Ningbo Maritime Electronics Co., LTD is a wholly owned enterprise by China Electronics Technology Group Corporation with a registered capital of RMB 30 million. We are professional for innovation and development of high-tech ship-borne (marine engineering) electronics, including maritime communication and navigation products. Moreover, we possess powerful capabilities of research, development, design, manufacturing, sales and services.
Our products consist of two series. One is radio communication and navigation device, including all the electronics information devices for ships, which key units are GMDSS, AIS, ECDIS and Navigation radar. The other is navigation-control equipments, just like unmanned surface vessel (USV), main engine remote control system, autopilot stand, etc. And now we possess 12 patents and some professional certifications, just like CCS, Cospas.
With professional design, high quality, good service and competitive price, our products are popular at domestic and abroad markets. Looking forward to cooperate with you!

Q: Where is your factory located? How can I visit it?
A: Our Head-office is in Ningbo and our Production line is located in Jiaxing. Ningbo of Zhejiang, 30 Minutes by car from Ningbo Airport,and Jiaxing of Zhejiang,30Minutes by high-speed train from Shanghai.

Q: How can I get the sample?
A:Samples could be sent within 3-5 days if there is in stock.Generally,sample is not free.

Q: What's the lead time?
A:If we have stocks of the item you need,we can send goods to you within 3-5 working days after 100% payment into our bank account.If we don’t have enough stocks,different products will take different days.Generally,it need around 30-35 days.

Q: How does your factory control product quality?
A: ISO9001 Certificated, independent quality control team with inspectors in our factory.

Q: Do you provide ODM/OEM service?
A: OEM/ODM is welcome, there are around 30 persons in our R&D team, and customized colours are optional. From the concept to finished goods, we do all (design, prototype reviewing, tooling and production) in the factory.

Q: What is your Minimum Order Quantity?
A: We sell you at least 10pcs for each item in normal order, but we also accept the sample order.

Q: What’s about shipping?
A: Small order can be shipped by air and large quantities can shipped by sea, no matter your assigned agent or ours, Our best advantage is that we’re located in Ningbo,which is China’s best harbor port!

Q: What’s your agency/distributor policy?
A: We have too many different policies according to target markets,so please send email for detailed discussion or talk face to face.
