Molybdenum disc 99.95% Mo products price per kg

Product Overview

Description



Molybdenum disc 99.95% Mo products price per kg





Usage:used for processing molybdenum disks, and foils. They are used in high-temperature vacuum and hydrogen-atmosphere furnace construction.
size:
Thickness: 0.1-20mm
Width: 20-600mm
Length: less than 1500mm
Your special requests are available

Applications

Mo has a unique property of which it's melting point can reach 2610 tungsten crucible is widely applied in high temperature vacuum furnace melting environment such as sapphire growing furnace, quartz glass melting furnace, and rare earth melting furnace. The working temperature of  Mo sheet is above 1500.

The melting process of the raw material for wool and fiber production is always by electrical heating with electrode, especially designed plate and Rod electrodes are generally used.
We can provide stable quality Mo material with plate and Rod electrodes based on uniform density, purity and fine metal grain strength property.
For glass melting application, high-purity, high-density, no crack property with other features of exact measurement and smooth surface has decisive influence on the success of quality control of glass melting and service life during meltng process.





1. Physical and chemical properties

(1) Density: 10.2
(2) Surface roughness: < 1.6

(3) Purity:W99.95%(min.)

(4) Application temperature environment:1500~1800



2. Specifications:

1)Dimensions and tolerances Unit:mm

thickness  (mm)	tolerance (mm)	Diameter  (mm)	tolerance (mm)	quality
2.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	cold rolling
3.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	cold rolling
5.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	forge
10.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	forge
20.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	forge
30.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	forge
40.0	± 0.05 or ±0.2	5-400	± 0.05 or ±0.2	forge



Special sizes can be manufactured based on customers' requirements



Advantage of our Mo glass melting electrodes:
- long term stock for your ready choice
- smoothed forged and chemically cleaned surface with quality
- uniform grain with densified microstructure ensures longer life time
- ready for use parts with precise machining tolerance.



Our testing for molybdenum sheets
Fe	Ni	C	Al	O	N
0.004	0.002	0.0028	0.0005	0.005	0.002
Si	Ca	Mg	Cd	Sb	Sn
0.0013	< 0.001	< 0.0005	< 0.001	< 0.0005	< 0.0005
P	Cu	Pb	Bi	Mo
< 0.001	< 0.0005	< 0.0005	< 0.0005	>99.95%



Package: Plastic paper inside, Polyfoam filled, Wooden box outside.



Shipping : by Air, By Sea, By Express, TNT/DHL/ FedEx etc.







1,reply your inquiry at the first moment

2,answer your question sincerely

3,to satisfy your requirement

4,deliver products timely

5,We will offer the tracking No.for checking



Zhengzhou Shibo Nonferrous Metals Products Co., Ltd. As a High & New technology Enterprise established in 2005, with registered capital of RMB two million. We are specialized in molybdenum-tungsten products, MoSi2&SiC heating elements, and high temperature laboratory Furnace, Including development, production and sales. Located at Zhongyuan Industry Area, Zhengzhou City, Henan Province, where is a hub of communications, commercial and trading center in China.
