45 mm kitchen cabinet ball bearing black dotted finish drawer slide

Product Overview

Description

45mm Stainless Steel Telescopic Ball Bearing Drawer Slide Rail

Name	Ball Bearing Drawer Slider	Weight	as per you requirement
Marerial	Cold Roll Steel /stainless steel	Length	8"(200mm)-28"(700mm)
Finish	Blue Zinc /Black /Rainbow zinc	Test	SGS 48hour
Usage	Kitchen table drawer	Loading capacity	50KGS/20inch/(500mm)
Type	2 and 3 fold drawer slide	Ball	1 balls/2 balls/3 balls/4 balls/5 balls
Width	45mm/42mm/35mm/27mm/17mm	Package	one pair/polybag,15 sets/CTN
Thickness	as per you requirement



Width	Thickness(mm)
17mm	0.8*0.8/1.0*1.0mm
27mm	0.8*0.8/0.9*0.9/1.0*1.0mm
30mm	0.6*0.6*0.6/0.7*0.7*0.7/0.8*0.8*0.8mm
35mm	0.7*0.7*0.7/0.8*0.8*0.8/0.9*0.9*0.9/1.0*1.0*1.0mm
40mm	0.7*0.7*0.7/0.8*0.8*0.8mm
42mm	0.8*0.8*0.8/0.9*0.9*0.9/1.0*1.0*1.0mm
45mm	0.8*0.8*0.8/0.9*0.9*0.9/1.0*1.0*1.0/1.2*1.2*1.2/1.2*1.2*1.5mm





Trade Terms	FOB
Payment Terms	L/C; T/T
MOQ	5000 pairs
Port	SHENZHEN/SHANTOU
Packing	According to your require.
Sample Availability	Free sample
Supply Capability	1000000 pairs per month
Delivery Time	20 days after received advance payment
Service	Provide OEM & ODM services
