Product Overview

Description

XHP750WCU-T4F Air Compressor







XHP750WCU-T4F Air Compressor

Maintenance is completed safely and efficiently on the XHP750 with an industry-leading enclosure design that is the most accessible air compressor ever created. Simple and safe access to all service components, from coolers to filters, is made possible by panels located on all sides of the machine. Located on each side of the compressors are two access doors, a pneumatic lift door and a drop-down door, which provide total service access to the interior compartment. A rear panel door on the canopy simplifies heat exchanger cleaning, while rear steps provide easy access to the radiator for engine coolant refills. A double-door design at the front of the air compressor protects and provides easy access to the operator control system. Efficient maintenance is further improved by the models’ central drain system. Centralized tubing and valve system drains allow operators to easily drain fluids from the radiator and oil and fuel tanks to a central location without having to crawl under the machine. A ladder at the front of the machine provides access to the enclosure roof for exterior maintenance needs.

Operation is made easy with the Doosan ViewPort control panel, which provides more detailed and preloaded resources than any other control panel in the market. An intuitive joystick control provides access to 15 operational parameters and easy access to relevant manuals, a machine maintenance schedule, and spare parts information. A Wi-Fi interface allows operators to access real-time data on laptops, tablets, or smartphones.

Available as an option is the patented IQ System® for cleaner air. Models with the IQ System feature an onboard aftercooler with 20 degrees approach, coalescing dual filtration system, and an exclusive, zero-discharge condensate removal system- all of which work together to protect compressors from contaminants to increase compressor productivity.

Built to excel in rugged conditions, the air compressor includes a heavy-gauge steel enclosure, heavy-duty tandem-axle running gear for easy towing, and construction-grade pedestal jack stand.

The XHP750 Tier 4F air compressor is a durable, reliable and powerful player within the Doosan Portable Power lineup. The XHP750 features a completely redesigned enclosure that has been engineered from the ground up to further enhance productivity and dependability. This hard-working, heavy-duty air compressor offers the best servicing capabilities in the industry, maximizing uptime in general construction, mining and abrasive blasting operations. Intuitive features and legendary performance make the XHP750 one of the most innovative portable air compressors in the world.



Powering Your Productivity

We ARE Doosan Portable Power!

One of the most trusted names in the construction, mining and oil explorations industries. Built on a legacy of quality and innovation since 1871. Rugged, reliable and American made air compressors, generators and light towers built to Power Your Productivity!

The Power of Air

Doosan Portable Power has one of the broadest comprehensive air compressor lines on the market. We have spent the last century perfecting our air compressors to fit your specific need.

It's All About UP-Time

Doosan Portable Power has a full range of mobile generators from 25-570 kVA. These generators are rugged, robust and built to be the easiest generators to use on the market. Set it and forget it!

Doosan Portable Power has one of the broadest comprehensive air compressor.

Doosan Portable Power has a full range of portable air compressors from 185 to 1600 cfm at 100 to 500 psi.  These durable, rugged and versatile compressors from Doosan are rigorously tested to ensure they perform in the harshest conditions.  Doosan Portable Power air compressors also have the most options available in the market so you can customize your equipment to fit your needs.



Products

• Air Compressors
• 185 thru 600 CFM
• 750 thru 1600 CFM
• High-Pressure
• Oil-Free
• Outside of the U.S.
• Utility Mount
• Airends
• Drill Modules
• Generators
• Light Towers
• Light Compaction



50 thru 1600 CFM Air Compressors

With over 100 years of experience, Doosan Portable Power provides large air compressors that are in a class of their own.  These portable compressors from Doosan are reliable and rugged to maximize uptime and productivity.  Every compressor from Doosan Portable Power is expertly crafted with galvanneal steel to resist corrosion and perform in the harshest conditions.







High-Pressure Air Compressors

Doosan Portable Power builds their compressors with the drilling customers in mind. Our compressors offer the right level of technology, from years of proven direct engine control to our innovative microcontroller and more. We listened to our customers and optimized the mechanical control of the inlet and with fuel efficiency and durability in mind.



Doosan Portable Power High-Pressure Air Compressors Comparison

Model	Free Air Delivery	Pressure
XHP750WCU-T4F	750 cfm (21.2 m³/min)	140 – 365 psi (9.7 – 24.1bar)
XHP1000WCAT-T4i	1000 cfm (28.3 m³/min)	365 psi (25.1 bar)
XHP1170WCU-T4F	1170 cfm (33.1 m³/min)	365 psig (25.1 bar)





SPECIFICATION

Model XHP750WCU T4F
COMPRESSOR
Free-Air Delivery – cfm (m³/min)	750 (21.2)
Rated Operating Pressure – psi (bar)	350 (24.1)
Pressure Range – psi (bar)	140-365(9.7-24.1)
Air Discharge Outlet NPT Size – in (mm)	2 (50.8)
Air Discharge Outlet Quantity	1
Compressor Oil Capacity – gal (L)	26.7 (101)
Emissions Tier Level	Tier 4 Final (T4F)
No. of Cylinders	6
Displacement – cu in (L)	543 (8.9)
Rated Speed – rpm	1800
Idle Speed – rpm	1350
Bhp @ Rated Speed (kW)	340 (254)
Electrical– volts	24
Engine Oil Capacity – qt (L)	23.2 (22)
Radiator Coolant Capacity – gal (L)	15.3 (58)
Altitude Capability – ft (m)	9000 (2743)
Fuel Consumption @ 100% load – gph (L/h)	46.1 (60.2)
FuelTank Capacity – gal (L)	128.1 (485)
DEFTank Capacity - gal (L)	10 (38)
DIMENSIONSWITH RUNNING GEAR
Overall Length – in (mm)	226.3 (5748)
OverallWidth – in (mm)	82.6 (2099)
Overall Height – in (mm) excluding exh pipe	101.3 (2573)
TrackWidth – in (mm)	69.3 (1760)
Tire Size – in	16
Shipping Weight w/o fuel – lb (kg)	11067 (5020)
Working Weight w/ fuel – lb (kg)	12213 (5540)
DIMENSIONSWITHOUT RUNNING GEAR
Overall Length – in (mm)	171 (4343)
OverallWidth – in (mm)	83 (2109)
Overall Height – in (mm) w/ shockmounts	95 (2413)
Shipping Weight w/o fuel – lb (kg)	10346 (4693)
Working Weight w/ fuel – lb (kg)	11669 (5293)
