RH AUDIO IP Network Adapter for PA System Background Music
- Category: >>>
- Supplier: Guangzhou Xinghongde Electronics Technology Co. Ltd.
Share on (60725483244):
Product Overview
Description
RH-AUDIO IP Network Adapter for PA System Background Music
Product Description
The RH-AUDIO IP PA System offers an ideal solution for some venues that need to do large-scale
paging and multi-zoned background music across multiple facilities and locations with complex
distribution and scheduling needs.
With IP network system you will enjoy a quicker and more flexible installation than traditional
wired analog systems.
1)Rack installing design with 1U height.
2)SMT circuit boards with highly stable performance.
3)Two controlled power outputs,power handling capacity 660W.
4)Support protocols of UDP,TCP/IP,IGMP.
5)2 line outputs for connecting conventional power amplifiers.
6)With one serial port for configuration with computer.
7)Standard Rj45 network port.
Widely used for any kind of public areas with complex inter-building distribution and
scheduling needs such as airports, ports,universities, schools, large gathering sites,
stadiums,industrial parks, parks, railways,highways, etc.
Built-in 8G memory for function of OFFLINE PLAYING
Specification
Network Port | Standard RJ45 |
Protocols | TCP/IP,UPP,IGMP |
Line input sensitivity | 470MV,RCA connections |
Audio output level | 775MV,RCA connections |
Audio output impedance | 470Ω |
T.H.D | ≤3% |
S/N | >70dB |
Working environment temperature | 5-40℃ |
Working environment humidity | 20%-80% |
Power Supply | AC 110V-240V/50Hz/60Hz |
Consumption | ≤36W |
Net Weight | 6.8Kg |
Dimension | 89(H)×485(W)×365(D)mm |
Connection
Company Information
Guangzhou Xinghongde Electronics Technology Co.,Ltd (Brand: RH-AUDIO) develops, manufactures, and markets highly reliable sound products of Commercial Sound System.
XINGHONGDE ELECTRONICS was incorporated in the year 2006 and began his business of manufacturing commercial PA sound system, providing applications of sound reproduction/reinforcement for a variety of venues such as conference halls,shopping malls,school auditoriums, churches, commercial buildings, industrial sites, gardens ,or an entire outdoor complex, etc.
On the way from beginning to now, we did not stop to be committed to serving our customers and providing them with more service in the business,thanks to the in-depth experience accumulated in the past time, and based on newly most advanced technology,we strive to keep the concept allowing you to truly enjoy a superb experience of technological revolution.
From the start, XINGHONGDE ELECTRONICS has striven to push the technology development,we do so by developing and manufacturing our products for markets looking for the most bang-for-the-buck,please take a moment to look over our entire product line, get involved with our innovation and share in the excitement.
XINGHONGDE ELECTRONICS has received the certificates of Quality Management System ISO 9001:2008, Environmental Management System ISO 14001:20004, Occupational Health & Safety Management OHSAS 18001:2007.
And our products are CCC (China Compulsory Certification),RoHS,CE,and FCC certified.
And our products are CCC (China Compulsory Certification),RoHS,CE,and FCC certified.
