  • 4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf
4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf

4.5 x 4.5X3.8/5/6/7mm 50mA 12v Dip Vertical push button tactile switch, through hole 4 pin, knob height 250gf

Share on (60726105116):


Price:$0.02 - $0.03

Quantity:


Product Overview

Description


   4.5 x 4.5mm through hole tact switch 4 pin





Product Display

















































Tact switch



Specification



Rating



0.5A 12V DC



Contact resistance



100mΩ max



Insulation resistance



100MΩ min at 500V DC



Dielectric strength



AC 500V for 1 min



Lifespan



100,000 Cycles



Practical temperature range



-25 to 85 degrees Celsius



RoHS



Yes



[Warm Tips]All informations above are for reference only; Particulars of all items are base on individual specification.
