2P Series 2/2 Way 24V 120v Plastic Solenoid shut off air Valve 2P025 08
- Category: >>>
- Supplier: Ningbo Yongyi Gaoke Pneumatics Co. Ltd.
Share on (60726742941):
Product Overview
Description
Product Description
Model: 2P Series 2/2 Way 24V 120v Plastic Solenoid shut off air Valve 2P025-08
Specification:
| Model | 2P025-06 | 2P025-08 |
| Working Medium | Air,Water,Oil,Gas | |
| Motion Pattern | Normally Closed | |
| Orifice Size(mm) | 2.5MM | |
| CV Value(Mm³/H) | 0.23 | |
| Port size | 1/8" | 1/4" |
| Operating Fluid Viscosity | 20 CS Below | |
| Operating pressure(kgf/cm²) | 0~0.7Mpa | |
| Max.Pressure Resisitance | 1.0Mpa | |
| Operating Tmeperature | -5~80℃ | |
| Voltage Reange | ±10% | |
| Maternal of Body | Engineering Plastic | |
| Material of Oil Seal | NBR,EPDM or VITON | |
