Product Overview

Description


SPD Description

Surge protective devices (SPD) connected between the power supply and the LED light in serial/shunt connection for protection of LED light from surge and transient over-voltage caused by the inducted lightning stroke or by internal power systems. Customized products are also available.

SP1 Series 120 - 277VAC 10kA Surge Protection Device for SSL Outdoor LED Street Lighting SPD
Input Voltage
120 - 277VAC 50/60Hz
MCV
320VAC
VPL(Up)
850V
Maximum Energy
820 Joules
SLC
＜5uA
Color
Green
OEM
Acceptable
SPD Features

IP65 SPD series

1.TUV / CE / Rohs certificates.

2.Interface Type: 3 Wires

3.Customer's drawings and designs are welcome.

4.Easy adjustment. competitive price, fast delivery and considerate after class service.

5.High protection level protect long life of the product.
