Tobee Effluent Handling
$12,600
Product Overview
Description
oil Pump
oil pump are usually designed and build in a number of different sizes, hence the components can be assembled in a variety of combinations.
These combinations must be carefully determined to operate the pump at the optimal production rate, material strength and temperature limits based on the Company’s catalogue.
a. Optimum Selection of Pump From the Performance Curve of the selected pump type, determine the number of stages required to produce the anticipated capacity based on the calculated dynamic head (TDH).
Note that the performance curves are single stage pump characteristic curves, hence the total stages required is determined from;
b. Housing Pressure Limit Maximum housing pressure will occur at pump shut in, when the maximum lift per stage is available. Worst case is when the pump is pumping against a closed valve.
538 Series Oil Pump Product Parameter
Series | Type | Capacity Range,Recommended Limits | Vane Type | |
|---|---|---|---|---|
| (m3/d) at 50Hz | (BPD) at 60Hz | |||
| 538 | TN2800 | 237-490 | 1789-3698 | Mixture |
| TN3300 | 370-640 | 2113-4981 | Mixture | |
| TN4200 | 500-860 | 2415-5320 | Mixture | |
| TN5500 | 478-1000 | 2943-7056 | Mixture | |
| TN6200 | 638-1200 | 4830-8905 | Mixture | |
| TN7500 | 850-1500 | 5660-10113 | Mixture | |
| TN11000 | 1050-1850 | 6037-13773 | Mixture |
Electric submersible pump Model Selection Basic Data | |
|---|---|
| Well Data | Casing size and weight, Tubing size, type and thread, Perforated oropen hole, Pump setting depth (measured and vertical), Deviation survey |
| Production Data | Wellhead casing pressure, Wellhead tubing pressure, Presentproduction rate, Production fluid level/Pump intake pressure, Static fluid level/Static Bottom hole pressure, Datum point, Bottom-hole temperature, Desired production rate, Gas-oil ration, Water cut. |
| Well Fluid Conditions | Specific gravity of water, Oil API or specific gravity, Specific gravity of gas, Bubble-point pressure of gas, Viscosity of oil, PVT data. |
| Power Sources | Available primary voltage, Frequency, Power source capabilities |
| Power Sources | Sand, Deposition, Corrosion, Paraffin, Emulsion, Gas,Temperature |
oil Pump
Contact us
Company Information
Aote Tianjin Pump Co., Ltd. was established in 2004,which is a professional manufacturer in production, sales, research and development of submersible motors and submersible pumps.
Main products: Submersible motor pumps, stainless steel submersible borehole pumps, sea water pumps, deep well submersible pumps, electric submersible oil pumps, sewage pumps, ZPQK/SXQK single suction and double suction mining submersible motor pumps, QZB/QHB axial flow pumps, mixed flow pumps,LX screw centrifugal pump and High voltage and low voltage 3 phase submersible Ac motor.
Our Services
1.Customized design is available.
2.All products have one year warranty and we sure the products will free from maintenance within warranty period.
3.Reply your inquiry in 24 working hours.
4.All products will be well packed before shipping.
5.Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers.
6.High quality material,advanced machines,skilled technicians to ensure quality.
7.Have our own engineer team,each machine is design as customer's specific requirement,the performance is higher 20%~40% than other factory with the same cost.
Payment terms
30% deposit by T/T in advance, pay 70% balance when the products are finshed.
