Product Overview

Description

UP6 4-11 kW Oil-Flooded Rotary Screw Compressors, up6-5tas-125 up6-5tas-150

UP6 7 TAS, UP6-7TAS, Oil-Flooded Rotary Screw Compressors, up6-5tas-125 up6-5tas-150

UP6-5TAS-125   UP6-5TAS-150   UP6-7TAS-125   UP6-7TAS-150   UP6-7TAS-210   UP6-10TAS-125   UP6-10TAS-150   UP6-10TAS-210   UP6-15TAS-125   UP6-15TAS-150   UP6-15TAS-210   UP6-5TAS-125-272   UP6-5TAS-150-272   UP6-7TAS-125-272   UP6-7TAS-150-272   UP6-7TAS-210-272   UP6-10TAS-125-272   UP6-10TAS-150-272   UP6-10TAS-210-272   UP6-15TAS-125-272   UP6-15TAS-150-272   UP6-15TAS-210-272



UP6-10TAS-125 UP6-10-125, UP6-10TAS-150, UP6-10-150,10hp.7.5kw 60hz small rotary screw air compressor, UP6 10 TAS 125 150

UP6 11-22 kW Oil-Flooded Rotary Screw Compressors with Integrated Air System

 15HP 20HP 25HP 30HP 40HP 50HP

UP6-15/UP6-15TAS, 60HZ,15HP,11KW, 125PSI 150PSI, ROTARY SCREW COMPRESSOR, MOUTNED WITH DRYER RECEIVER INGERSOLL RAND

UP6-25/UP6-25TAS,25HP,18.5KW, 125PSI 150PSI,200PSI, OIL INJECTED COMPRESSOR, MOUTNED WITH DRYER RECEIVER FILTER, INGERSOLL RAND

UP6-20/UP6-20TAS,20HP,15KW, 125PSI 150PSI,200PSI, OIL INJECTED COMPRESSOR, MOUTNED WITH DRYER RECEIVER FILTER, INGERSOLL RAND

UP6-30/UP6-30TAS,30HP,22KW, 125PSI 150PSI,200PSI, INGERSOLL RAND ROTARY SCREW COMPRESSOR, LUBRICATED COMPRESSOR UP6 30 TAS

UP6-50/UP6-50TAS,50HP,37KW, 125PSI 150PSI,200PSI,oil flooded type compressor, screw compressor, UP6 50PE 50



UP6 15 125 UP6 15 150 UP6 20 125 UP6 20 150 UP6 20 200 UP6 25 125 UP6 25 150 UP6 25 200 UP6 30 125 UP6 30 150 UP6 30 200 UP6 40 115 UP6 40 125 UP6 40 150 UP6 40 200 UP6 50PE 115 UP6 50PE 125 UP6 50PE 150 UP6 50PE 200



Offering an exceptional value without sacrificing the reliability you’ve come to expect from Ingersoll Rand, the UP6 Series of oil-flooded rotary screw compressors provides a complete air solution in an easy to use, easy to access compact package, delivering efficient performance. And with the optional Total Air System (TAS) included, you'll get clean, dry air in a cost-effective single package.



We can help take your productivity further

Since 1872, when we introduced our first air compressor,we at Ingersoll Rand have inspired progress by driving innovation
with technology that improves the way the world works. We’re the technology leader in compressed air not only because we develop class-leading products, but also because we stand behind our customers in everything we do.
A compressed air system is a considerable investment. So, you want to be confident that the particular system you’re choosing is a smart investment. You want the peace of mind that comes from knowing the equipment won’t need to be replaced prematurely. With Ingersoll Rand, you buy once, not twice. We’ll ensure you have the right sized equipment, delivering the appropriate air quality to meet your demands.



Features:



• Efficient Operation: Advanced high-efficiency combination cooler with roof-mount package exhaust enables easy ducting
• Easy to Use: Simple diagnostics, auto start/stop and a spacious design to maximize serviceability makes the UP6 Series easy to operate
• Safer Work Environment: Whisper quiet operation allows for installation closer to point-of-use, reducing costs and ensuring a better and safer work environment
• Enhanced Reliability: Fewer connections and smart integration eliminates leaks and pressure drops maximizing reliability
• Extend Equipment Life: Closely maintained discharge pressure avoids excessive pressure bands increasing downstream tool and equipment life
• Compact Footprint: Small footprint frees up valuable floor space and reduces install costs







Simply advanced

The compressor's air end, interconnecting piping, and separation system are all integrated into one simple design. This eliminates leaks and pressure losses-maxing efficiency and performance. The spin-on oil and separator cartridge make service and maintenance extremely user-friendly.





FEATURES:

• Efficient Operation: Advanced high-efficiency combination cooler with roof-mount package exhaust enables easy ducting
• Easy to Use: Simple diagnostics, auto start/stop and a spacious design to maximize serviceability makes the UP6 Series easy to operate
• Safer Work Environment: Whisper quiet operation allows for installation closer to point-of-use, reducing costs and ensuring a better and safer work environment
• Enhanced Reliability: Fewer connections and smart integration eliminates leaks and pressure drops maximizing reliability
• Extend Equipment Life: Closely maintained discharge pressure avoids excessive pressure bands increasing downstream tool and equipment life
• Compact Footprint: Small footprint frees up valuable floor space and reduces install costs





SPECIFICATION:





MODEL	POWER	CAPACITY	MIN. PRESSURE	MAX. PRESSURE	VOLTAGE  OPTION	DRYER  BUILT-IN
	HP	m3/min	bar(g)	bar(g)	V
UP6-5TAS-125	5	0.52	4.5	8.6	230	115v/1ph/60hz
					380
					460
UP6-5TAS-150		0.45		10.3	230
					380
					460
UP6-7TAS-125	7	0.79		8.6	230
					380
					460
UP6-7TAS-150		0.71		10.3	230
					380
					460
UP6-7TAS-210		0.50		14.5	230
					380
					460
UP6-10TAS-125	10	1.08		8.6	230
					380
					460
UP6-10TAS-150		0.96		10.3	230
					380
					460
UP6-10TAS-210		0.68		14.5	230
					380
					460
UP6-15TAS-125	15	1.55		8.6	230
					380
					460
UP6-15TAS-150		1.42		10.0	230
					380
					460
UP6-15TAS-210		1.08		14.5	230
					380
					460
UP6-5TAS-125-272	5	0.52		8.6	230
					380
					460
UP6-5TAS-150-272		0.45		10.3	230
					380
					460
UP6-7TAS-125-272	7	0.79		8.6	230
					380
					460
UP6-7TAS-150-272		0.71		10.3	230
					380
					460
UP6-7TAS-210-272		0.50		14.5	230
					380
					460
UP6-10TAS-125-272	10	1.08		8.6	230
					380
					460
UP6-10TAS-150-272		0.96		10.3	230
					380
					460
UP6-10TAS-210-272		0.68		14.5	230
					380
					460
UP6-15TAS-125-272	15	1.55		8.6	230
					380
					460
UP6-15TAS-150-272		1.42		10.0	230
					380
					460
UP6-15TAS-210-272		1.08		14.5	230
			380
			460
