High speed drum twister laying up big diameter cable machine
- Category: >>>
- Supplier: Shanghai Shineworld Group Co. Ltd.
Share on (60729235276):
Product Overview
Description
Technical Parameter
Model | JPD-2500 | JPD-3150 | JPD-3600 | |
Maximum laying up OD(mm) | 20-120 | 25-130 | 25-130 | |
Maximum cross-section(mm²) | 50 | 30 | 30 | |
Laying up pitch | Step-less, adjustable | Step-less, adjustable | Step-less, adjustable | |
Maximum linear speed(RPM) | 50 | 40 | 40 | |
Maximum haul off force | Standard(KN) | 3000 | 3000 | 3000 |
With 96pcs steel wire armoring(KN) | 5000 | 6000 | 6000 | |
Non-metallic taping device | Maximum speed(RPM) | 500 | 500 | 500 |
Taping pitch(mm) | Step-less, adjustable | Step-less, adjustable | Step-less, adjustable | |
Taping reel | 600X80 | 600X80 | 600X80 | |
Taping width(mm) | 15-80 | 15-80 | 15-80 | |
Metallic taping device | Maximum speed(mm) | 300 | 300 | 300 |
Taping pitch | Step-less, adjustable | Step-less, adjustable | Step-less, adjustable | |
Taping reel(mm) | Φ800XΦ200 | Φ800XΦ200 | Φ800XΦ200 | |
Steel Tape width(mm) | 15-60 | 15-60 | 15-60 | |
Central pay off(mm) | PN2000-2500 | PN2500-3150 | PN2500-3600 | |
Pay off stand(mm) | PN1250-1600 | PN1600-2000 | PN2000-2500 | |
Take up drum head size(mm) | PN2000-2500 | PN2500-3150 | PN2500-3600 | |
Steel wire armoring specification | PND500 | PND500-630 | PND500-630 | |
Main motor power(KW) | 45 | 55 | 75 | |
Central payoff stand motor power(KW) | 22 | 45 | 55 | |
Payoff stand motor power(KW) | 15 | 15 | 18.5 | |
Traversing stand motor power(KW) | 2.2 | 2.2 | 2.2 | |
Take up stand motor power(KW) | 5.5(2units) | 5.5(2units) | 7.5(2units) | |
Central height(mm) | 1000 | 1000 | 1000 | |
Product show
Advantage:
1. Assembly structure of the twisting arms and pressure-bearing plate: all the parts will be assembled together after all the processing, which avoided the possible defects caused by the processing after assembling. so a more accurate and reliable operation. Higher speed, lower noise and more reliable quality
2. Touch panel with PLC and PROFIRBUS busbar, which realize a well-organized on-and-off, operation and cyclical synchronization of the different motors. DANFOSS converter controls all the AC motors. Advance electrical control, easy operating, and reliable operation
3. Converter control all the AC motors in the line: chief motor, pay-off motors, take-up motors, traversing motors, driven motors, taping motors and rotatory take-up. Stable function, less defects, easy maintenance.
4. Pitch can be set, changed and displayed on touch panels, and also the laying (to right or left),point moving and fast moving can be set on touch panel
5. Tension control of the take-up can be set changed and displayed on the touch panel.
6. THE PAY OFF IS Controlled by a separate motor which can realize a synchronous rotation to the rotary take up. Protection devices and auto-stop at defects; easy operation and reliable
Procedure
Success Case
Related Products
Company Power
Exhibition
FAQ
1,Q: What is your main brand for the electrical and mechanical parts?
A: China famous brand
2, Q:could we appoint the parts brand?
A: Yes, ABB, SIEMENS, Danfoss, or theirs that you like.
3, Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge
4, Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge
5, Q: could you do the design for the whole plant
A: Yes , we can.
6, Q: could you offer the production process design
A: Yes , we can.
7, Q: what is the difference with other supplier?
A: what we could offer to other customer is not only the machine itself, also we could offer: factory design, production process design , QC control and education and assist machine and raw material offering .
8.Q:What's the payment terms?
A:T/T,30% deposit and 70% balance before delivery.
9, Q:How long the guarantee:
A: one year and charge for repair the whole life.
