220V High Quality Mini Hydraulic Power Unit power distribution unit
220V High Quality Mini Hydraulic Power Unit power distribution unit
220V High Quality Mini Hydraulic Power Unit power distribution unit
220V High Quality Mini Hydraulic Power Unit power distribution unit
220V High Quality Mini Hydraulic Power Unit power distribution unit

220V High Quality Mini Hydraulic Power Unit power distribution unit

Share on (60730174102):


Price:RUB 9,662.53 - RUB 11,149.07

Quantity:


Product Overview

Description

Product Description

Product Application

220V High Quality Mini Hydraulic Power Unit power distribution unit is designed exclusively for Auto hois,with power up,gravity down function.Such product can be applied to different voltage and frequences and the lowering movement is cotrolled by the manual release valve. The power unit also applies to different kinds of hydraulic fork lift and scissors lift.

SPECIFICATIONS FOR 220V High Quality Mini Hydraulic Power Unit power distribution unit
Model
Motor Volt
Motor Power
Rated Speed
Displacement
System pressure
Tank  Capacity
YD-AC3DESLDFH03DS3
380V
2.2KW

2850RPM
2.1mL/r
18Mpa
12L
YD-AC2DESLPFH03DS3
220V
2.2KW
2.1mL/r
18Mpa
12L

Special Notes

1) The duty if this hydraulic power unit is S3.I.E.,30 seconds on and 270 seconds off.

2) Clean all the hydraulic parts concerned before mounting the power unit.

3) Viscosity of the oil should be 15-68cst.

4) This power unit should be horizontal.

5)  Check the oil level in the tank after the first star of the power unit.

6) Change the oil after the first 100 hours of using the power unit,then change the oil every3000 hour.

Certifications
Detailed Images

Hydraulic power unit Parts

Name: Motor

Brand: LIFT

Original: China

AC motor,International standard steel casting motor with CE & SA certificntion.

Center Manifold Features

Name: Center manifold
Brand: LIFT
Original: China
According to customers requirement,We designed for the usages in different flow and mounting condition.

Hydraulic power unit Parts

Name: Spare part
Brand: FELIFT
Original: China
 Solenoid valve: Max pressure:300bar

                            Max flow:20L/min

                            Coil power:18W

Oil Tank Main Features

Name: Oil tank
Brand: LIFT
Original: China

International standard palstic tank

Colour:White

"W" type:Horizontal    "L" type:Vertical

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* One year warranty

* Our experienced engineers would give you the best technical support as they can

Packing & Delivery
Packaging
Size
1100 (L) * 1000(W) * 1200(D)mm
Weight
1.2 T



Packaging Details
The normal package is pallets(Size:1100 (L)*1000(W)mm).
