Product Overview

Description

Product Description

Product Application

12V small RV hydraulic power units with Certificate CE consists of high pressure gear pump,DCmotor,mul-functional manifold,valves,tank,ect.It features stable pertormance and compact structure,and can be widely used in automotive,garden machineries,machine tools,logistics equipments etc.
SPECIFICATIONS FOR 12V small RV hydraulic power units with Certificate CE
Model
Motor Volt
Motor Power
Rated Speed
Displacement
System pressure
Tank  Capacity
YD-DC12AAWEA16AS3
12V DC


0.8KW

2500  RPM
0.5mL/r


13Mpa
1.4L
YD-DC24AWADB20AS3
24V DC
0.63mL/r
2L

Special Notes

1) The duty if this hydraulic power unit is S3.I.E.,30 seconds on and 270 seconds off.

2) Clean all the hydraulic parts concerned before mounting the power unit.

3) Viscosity of the oil should be 15-68cst.

4) This power unit should be horizontal.

5)  Check the oil level in the tank after the first star of the power unit.

6) Change the oil after the first 100 hours of using the power unit,then change the oil every3000 hour.

Certifications
Detailed Images

Hydraulic power unit Parts

Name: Motor

Brand: LIFT

Original: China

DC motor,International standard steel casting motor with CE & SA certificntion.

Center Manifold Features

Name: Center manifold
Brand: LIFT
Original: China
According to customers requirement,We designed for the usages in different flow and mounting condition.

Hydraulic power unit Parts

Name: Spare part
Brand: FELIFT
Original: China
 Solenoid valve: Max pressure:300bar

                            Max flow:20L/min

                            Coil power:18W

Oil Tank Main Features

Name: Oil tank
Brand: LIFT
Original: China

International standard palstic tank

Colour:Black

"W" type:Horizontal    "L" type:Vertical
