20459353 HX55/HT55 Turbo 3591077 With D12 D12C Engine
20459353 HX55/HT55 Turbo 3591077 With D12 D12C Engine
20459353 HX55/HT55 Turbo 3591077 With D12 D12C Engine
20459353 HX55/HT55 Turbo 3591077 With D12 D12C Engine
20459353 HX55/HT55 Turbo 3591077 With D12 D12C Engine

20459353 HX55/HT55 Turbo 3591077 With D12 D12C Engine

Share on (60730388233):


Price:$260.00 - $290.00

Quantity:


Product Overview

Description


Product Description


Part Number3591077
Previous versions3591077D, 3591077-D, 3591078, 3533544, 3165219, 3533544, 3532692, 452164-0001, 712922-0002
OE number1677098, 1677726, 1677725, 1676089, 3165219, 425720
Year1998-01
ApplicationTRUCK FH12, FM12
Manufacturer Part Number3533545, 3533546, 3531858, 3532692, 3591078, 3537913, 3591949
CHRA4027027 (1153055902)  NEW IN STOCK
Turbo ModelHX55-E9861E/T25VB15A, HX55
EngineD12, D12C, D12C, D380 Euro 3
Engine Manufacturer3591078
Customer No3165219
S/NW060807595
Displacement12.14L, 11950 ccm, 6 Cylinders
Power450/460 HP
Angle α (compressor housing)130°
Angle β (turbine housing)180°
Bearing Housing3590231/4039258  NEW IN STOCK
Turbine Wheel3533543/4038182 (Ind. 86. mm, Exd. 80. mm, 12 Blades) (1153055435)  NEW IN STOCK
Comp. Wheel4041666 (Ind. 65. mm, Exd. 99. mm, 7+7 Blades)  NEW IN STOCK
Back plate3528096 (1153055300)  NEW IN STOCK
Heat shield Number3529846/3533038 (1153055340)  NEW IN STOCK
Repair Kit3580762/3575181 (1153055750)  NEW IN STOCK
Turbine Housing4039644
Compressor Cover3591065
Gasket (turbine inlet)409038-0000 (132040, 52231083002)
Gasket oil inlet147837 (210023)
Gasket (oil outlet)210060 (2475013)
Replaced By4049337
