factory price XMTD 2001/2002/2301/2302 digital intelligent PID temperature controller
Technical Parameter
XMTD series digital thermostat control can be combined with diverse thermocouples to render an automatic measuring and control over the temperature. The adjusters therein serve for the entire measurement distance indication and full range regulating. The adjuster is the on-off regulating method. The adjusters have functions of the cold end automatic compensation and couple-breakage protection. The adjusters are nice-looking in style, easy for use cheap in price, providing a relatively high comparability between performance and price, widely used in the plastic machinery, packing machines, food-processing machinery as well as the light industrial, textile printing and dyeing industries which require the control on the temperature.
| Name | XMTD digital temperature controller |
| Power source | AC220V, 50/60Hz |
| Power consumption | less than 5W |
| Working temperature | 0~60°C |
| Relative humidity | <85%RH, without corrode. |
| Capacity of touch point | AC250/5A(Resistive load) for SSR use |
| PID regulation | output 0~10mA(or 4~20mA) , load resistance 800Ω (or 250Ω) |
| Temperature Coefficient | ≤0.05%℃ |
| Proportion Cycle | relay: 30 secs., no connection point: 2 secs. |
| Dimension | 72*72 |
