Высококачественный драйвер двигателя 5,5 кВт cnc Шпиндельный серводвигатель

Высококачественный драйвер двигателя 5,5 кВт cnc Шпиндельный серводвигатель

Category: Motor Driver >>>
Supplier: Shenzhen,Guanhong,Technology,Co.,Ltd.

Price:

Price in USD:Details

Quantity:

Product Overview

Description

top quality 5.5KW driver motor cnc spindle servo motor driver

Product Description

Input Power	Rated Voltage/ frequency	Three-phase 380V/480V;50Hz/60Hz
	Allowable Voltage range	+10%~-15%
	Allowable Frequency Fluctuation	± 5%
Control Features	Control Mode	PWM Vector Control
	Speed Adjustment Range	0.01~500Hz
	Speed Stabilization Precision	± 0.1%
	Acceleration/ Deceleration time	0.05~3000Hz/s
	Torque Control	200% Rated torque output;Torque precision ±5%
	Position Control Precision	±1 Pulse
	Braking Mode	Powered Braking
	Overload Capacity	Twice Overload
I/Os	Digital Input	10 points , NPN or PNP(Optional)
	Digital Output	6 points , NPN
	Relay Output	2pcs ,DC30V/1A Or AC250V/1A
	Analog Input	2 inputs, A0:±10V; A1: 0~±10V Or 4~20mA(Optional)
	External Pulse Input	1 type ,ABZ phase pulse ,Pulse+Direction Or CW (Optional)
	Motor Encoder Input	1 type,RS422 TTL , Rotatry Connector(Optional)
	Motor Encoder Output	1 pcs,RS42TTL ,Output Frequency Range: 0~1MHz
Protection Function	Over-Voltage Protection,Low-Voltage Protection,Over-Current Protection,Over-Heat Protection, module Protection,Overload Protection,Output Short Circuit Protection,Encoder's abnormal Protection
Working Environment	Operating Site	The product shall be mounted verticlly in the electric control cabinet with good ventilation.The product shall be installed in the environment free from direct sunligh ,dust,corrosive gas,sombustible gas,oil mist,steam and drip
	Ambient Temperature	-10℃ ~ +45℃
	Humidity	5~90%, not allow condensing
	Altitude	0~3000Meters,derated above 1000m, the rated output current shall be decreased by 1% for every rise of 100m
	Vibration	Under 20Hz:1G; 20~50Hz: 0.2G
