Manufacturer high temperature vacuum dryer oven
- Category: >>>
- Supplier: Changzhou Dagui International Trade Co. Ltd. [Jiangsu China]Changzhou
Share on (60731267286):
Product Overview
Description
Product Description
Manufacturer high temperature vacuum dryer oven
Product details
| name | vacuum dryer |
| model number | YZG-600 |
| layers of baking shelf | 4 |
| layers of baking shelf (mm) | 81 |
| size of baking tray (mm) | 310*600*45 |
| number of baking shelf | 4 |
| temperature inside chamber (℃) | 35-150 |
| Product Keywords | high temperature vacuum dryer oven |
| name/specification | YZG-600 | YZG-800 | YZG-1000 | YZG-1400 | FZG-15 |
| inside size of chamber (mm) | Φ600×976 | Φ800×1247 | Φ1000×1527 | Φ1400×2054 | 1500×1220×1400 |
| outer size of chamber (mm) | 1135×810×1020 | 1700×1045×1335 | 1693×1190 ×1500 | 2386×1657 ×1920 | 2060×1513×1924 |
| layers of baking shelf | 4 | 4 | 6 | 8 | 8 |
| layers of baking shelf (mm) | 81 | 82 | 102 | 102 | 122 |
| size of baking tray (mm) | 310×600×45 | 520×410× 45 | 520×410×45 | 460×640×45 | 460×640×45 |
| number of baking shelf (mm) | 4 | 8 | 12 | 32 | 32 |
| permitted pressure inside the pipe of baking shelf (Mpa) | ≤0.784 | ≤0.784 | ≤0.784 | ≤0.784 | ≤0.784 |
| temperature inside chamber (℃) | 35-150 | 35-150 | 35-150 | 35-150 | 35-150 |
| vacuun in idle insid chamber (Mpa) | -0.1 | -0.1 | 0.1 | 0.1 | 0.1 |
| under the condition of -0.1 Mpa and 110℃,evaporation rate of water,kg/m2 hr | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 |
| when condensor is not used, model and power of vacuum pump,kw | 2X-15A | 2X-30A | 2X-30A | 2X-70A | 2X-70A |
| 2KW | 3KW | 3KW | 5.5KW | 5.5KW | |
| when condensor is not used, model and power of vacuum pump,kw | SZ-0.5 | SZ-1 | SZ-1 | SZ-2 | SZ-2 |
| 1.5KW | 2.2KW | 2.2KW | 4KW | 4KW | |
| weight of drying chamber (kg) | 250 | 600 | 800 | 1400 | 2100 |
