Performance Features:
1.Double servo spindle, Separated servo control for machine head and shuttle,
Simple mechanical action, Low maintenance rate, High stability, Stable & ultra-quiet running. 2.Machine head lifting: easy for thick material feeding and coming out, ensuring smooth embroidering.
3.Bar code scanning: automatic pattern selection and sewing confirmation
4.Moveable machine head: large sewing range while machine taking less space
5.No need to wait, realize left and right circular continous sewing with seamless design match, greatly improve the work efficiency.
Technical parameters
| Model | YS-L-8020 |
| Spindle servo | Double servo drives (upper shaft & down shaft) |
| Max. stiching speed | 3000RPM |
| Hook | Double size hook |
| Head lifting height | 55mm |
| work clamp height | 60mm |
| Needle pitch | 0.05-10mm |
| Trimming way | Stepping motor trimmer |
| Maximum needle number | 100 million stitches (Max. 2 million stitches for one design) |
| Stitch type | Plain stitch |
| Max sewing thickness | 8mm-25mm |
| Embroidery frame drivers | Servo, Closed-loop stepping |
| Breakage detection mode | Spring lever detection |





Q1.Are you manufacturer?
A:Yes, we are manufacturer with more than 11 year's experience.
Q2.Where are you ? Can we go to China and visit your factory?
A:Yes,sure.We are in Zhejiang ,China.Welcome to our factory.
Q3.What about payment term?
A:The payment is T/T,30 days after received 30% deposit,70% before shipment.
Q4:What is the packing?
A:Woonden case or vacuum package.Container loads as per the machine size.
Q5:Can I put my LOGO/brand on the machines and finish products?
A:Yes, Sure. Just send us your artwork.
Q6.Q:How long we will get the machine?
A:We and our clients usually choose the delivery by sea, so once you place the order,
we will arrange the produce within 2 days, and about 20-50days(depend the destination port) you will get the machine.
