High speed Computerized Multi Head Quilting Embroidery Machine

Product Overview

Description

XJ-252 Computerized Multi Head Quilting Embroidery Machine



This series accept non-standard number of heads and needle pitch customized



Language: chinese,english and Russian.



The most advanced software, easy to operate, simple, stable. if software updates, we will send you, and all of them are free the whole life.



APPLICATIONS:



Quilting processed goods: clothing,sleeping bags,summer quilts,mattresses,bedspreads,seat cushions,etc.

FEATURES:

1)integrate computerized quilting and embroidery



2)Automatic color change,arbitrary head for quilting and embroidery



3)Continuous quilting of independent pattern,skip quilting function



4)unlimited and contiuous quilting and embroidery in Y direction,front and rear automatic tensioning systems.



5)3.5 inch floppy disk generally used for common embroidery machine,support USB flash memory,readable many EMBROIDERY format.



6)Independent presser foot operation to make the product have three-dimensional aesthetics



7)Rolling shaft design in Y direction,cloth can be continuously sewn or quilted



8)Simple,convenient and feasible operation



9)Rotating speed control,power-off protection,power-off meoory function



10) Broken line detection,roll back quilting and embroidery function



11)Advance and retreat function at a high or low speed



12) Trimming system,trimming length control,line drawing concentration system,stability and reliablity.

Main shaft motor	Servo motor
Rotary hook	big rotary hook
Power	380v/50hz
Rotary hook speed	800rpm
Power consumption	6-7kw

Modle	Heads	Head distance	Needle Qty	Quilting Area x direction           face width		Dimensions
252	52	50.8	2	50.8/101.6	2640+2640	8050X1980X1500mm
