5.5 hp 6.5 hp Gasoline Engine
- Category: >>>
- Supplier: Taizhou Belten Mechanical & Electrical Manufacture Co. Ltd.
Share on (60733406711):
Product Overview
Description
| Model: | BT-152F | BT-154F |
| Engine Type: | 1-cylinder,4-stroke,Air-cooled ,gasoline engine, OHV, 250 , inclined single cylinder | |
| Displacement: | 98cm3 | 87CC |
| Bore x Stroke: | 52*46 | 54*38 |
| Max. Torque: | 3.2N.M | 3.5N.M |
| Compression Ratio | 8.5:1 | 7.7:1 |
| Ignition system: | C.D.L | C.D.L |
| Starting system: | Recoil | Recoil |
| Fuel tank capacity: | 1.6L | 1.6L |
| Engine oil system capacity | 0.37L | 0.37L |
| Max. Power Output: | 2.5HP 1.7KW | 2.5HP 1.7KW |
| Rated Power Output: | 1.8HP 1.3KW | 1.8HP 1.3KW |
| Min. Fuel Consumption: | 290g/kw/h | 290g/kw/h |
| Weight | 10kgs | 10kgs |
| Dimension (L*W*H) | 31.5*27.5*32 | 31.5*27.5*32 |
| Model: | BT-168F (GX160) | BT-168F-1 (GX200) | BT-170F (GX210) |
| Engine Type: | 1-cylinder,4-stroke,Air-cooled ,gasoline engine, OHV, 250 , inclined single cylinder | ||
| Displacement: | 163cm3 | 196cm3 | 210cm3 |
| Bore x Stroke: | 68*45(mm) | 68*54(mm) | 70*54(mm) |
| Max. Torque: | 10.8/2500 N.W/rpm | 13.2/2500 N.W/rpm | 14.1/2500 N.W/rpm |
| Compression Ratio | 8.5:1 | 8.5:1 | 8.5:1 |
| Ignition system: | TCI | ||
| Starting system: | Recoil / Electric | ||
| Fuel tank capacity: | 3.6L | 3.6L | 3.6L |
| Engine oil system capacity | 0.6L | 0.6L | 0.6L |
| Max. Power Output: | 5.5/3600 HP/rpm | 6.5/3600 HP/rpm | 7.0/3600 HP/rpm |
| Min. Fuel Consumption: | 395 g/kw-hours | ||
| Continuous Operaring Time | 4 hours | ||
| Weight | 14KGS/15KGS | ||
| Dimension (L*W*H) | 39*33*34CM | ||
Why choose Belten
Professional Genset manufactrurer with R&D capacity
Reliable quality, reasonable price, desirable service
Tell us your demand, provide what you want
Contact us now, let's make a deal.........
Company Information
FAQ
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located?
A: Our factory is in Taizhou City, Zhejiang Province, China.
It's near Ningbo & Shanghai port.
It's about 15minutes from Luqiao air port by car, 45 minutes from Wenlin train station by car.
3.Q:What is the material of your products
A: Iron,Steel,plastic,etc.
4.Q:How about quality control in your factory?
A:"Quality is first, Customers are friends".
Taizhou Belten people are always paying great attentions to quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
5.Q:How about guarantee?
A: It's within three months after goods is discharged in the destination.
During that period,if some breakdown easily spare parts need to change,my factory offers free.
For example, fuel cock,spark plug,starting hand,etc.
