• Generator set with AVR, Voltage adjust. • Low Oil sensor protection. • Cradle, Overall protection, easy move and storage. • Widely option for control panel, EU, US and AU receptacle for choice. • Self-start and remoter start as an optional. • Frequency, 50/60 Hz. Voltage, including, 110/150/120/220/230/240V to be optional. • Wheels and handle optional • Start, Recoil or E-start. • Single Phase or Three Phase, (380/400/415V)optional.
Model
EP2500
EP4000
EP4500
EP6500
EP15000E
AC Frequency (Hz)
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
AC Output voltage(V)
110;120;220;230;240;
110;120;220;230;240;
110;120;220;230;240;
110;120;220;230;240;
110;120;220;230;240;
Rated AC Output
2000W
2800W
3500W
5000W
10000
Max.AC Output
2200W
3000W
4000W
5500W
11000
Power Factor
1.0
1.0
1.0
1.0
1.0
DC Output
12V/8.3A
12V/8.3A
12V/8.3A
12V/8.3A
12V/8.3A
Engine
GP160
GP200
GX270
GX390
GX690
Type
Air-Cooled, Four-Stroke, OHV Single Cylinder
Air-Cooled, Four-Stroke, OHV Single Cylinder
Air-Cooled, Four-Stroke, OHV Single Cylinder
Air-Cooled, Four-Stroke, OHV Single Cylinder
V-2* Cylinder Air-cooled 4-stroke OHV
Displacement(cc)
163
196
270
389
688
Starting System
Recoil
Recoil
Recoil
Recoil
Electric with battery
Lubrication oil
SAE 10W/30
SAE 10W/30
SAE 10W/30
SAE 10W/30
SAE 10W/30
Fuel Tank Capacity(l)
12
12
25
25
25
Continuous Work(h)
13
12
7.4
7.4
4.6
Noise Level LwA dB(A)
73
73
73
73
73
Dim(mm)
590X445X435
590X445X435
695 x 530 x 570
695 x 530 x 570
913 x 541 x 570
Gross Weight(kg)
42
43
73
73
161
20ft Container Qty
235
235
136
136
72
40ft Container Qty
480
480
280
280
150
Warranty
1 Years Limited Warranty
1 Years Limited Warranty
1 Years Limited Warranty
1 Years Limited Warranty
1 Years Limited Warranty
Detailed Images
Engine Features
• Overhead valve (OHV) design, lower operation temperature, powerful drive and reliability and durability, and it save more oil.
• Cast iron casing does not only effectively improve lubrication, but also makes engine more wear-resistant and prolongs engine life. • Automatic alarm and stop at low oil level, which prevents the engine to work at low oil level and gives more protection to engine. • Metal cam and forged crankshaft makes engine more reliable and durable.
Alternator Features
Alternator full power design
• Alternator brushless type design, free maintenance cost • Alternator IP23 protect • Alternator F class insulation • Alternator single bearing design • Alternator with aluminums cooled fan • multiform voltage choose including, 110/150/120/220/230/240V
Packing & Delivery
Packaging and Delivery
Size
Depend on the gasoline generator power
Weight
Depend on the gasoline generator power
Packaging and Delivery Details
1.Carton packing, optional color carton and pallet.
2.According to customers special request.
3.Our delivery time usally 25 to 30 days after receiving the deposit.
