G80 Clevis Self locking Hook

Product Overview

Description

G80 Clevis Self-locking Hook

Art  No.	Size	WLL	Breaking  Load	E±2	B ±0.5	H±1	N±1.5	R	Weight
	mm	t	t	mm	mm	mm	mm	mm	kgs/pc
GK0201	6	1.12	4.48	29	8.5	19.5	34	95.5	0.50
GK0202	7/8	2	8	34	9.5	24	46	121	0.80
GK0203	10	3.15	12.6	44	12	30	56	146	1.50
GK0204	13	5.3	21.2	52	15	40	69	182	2.80
GK0205	16	8	32	60	18	50.5	86	218	5.60
GK0206	20	12.5	50	83	25	55	100	240	7.50
GK0207	22	15	60	88	25.5	67	98	276.5	11.50
GK0208	26	21.2	84.8	95.5	30	75	110	310.5	18.50
GK0209	32	31.5	126	160	36	97	166	411.5	49.10
