Capping and Rod Grinder DM100
Product Description
Cap and rod gringding machine is mainly used when grinding the connecting rod and its end faces for the engines of automobile,tractors and so on.
Feature
1. Table cross travel movements by linear guides,easy to operate.
2. Table can be adjusted+0.3°,to meet the job requirments.
3. Cross feed grinding,high precison screw,,Ensure accuracy
4. Cabinet optional tools
Specification
Model | DM100 | DM50 |
Max inside dimension of cap | 275mm | 160 mm |
Max thickness of the connecting rod | 100mm | 50mm |
Grinding wheel speed | 2800rpm | 2800rpm |
Main motor power | 0.75KW | 0.75KW |
Overall dimensions(L*W*H) | 920*750*350mm | 520*350*310mm |
Tool cabinet dimenstion(L*W*H) | 960*580*665mm |
|
Packing dimensions(L*W*H) | 1360*890*1200mm | 650*380*420mm |
N/G Weight | 150/180kgs | 35kg/45kgs |
