new design metal fence panel roll forming machine
- Category: Tile Making Machinery >>>
- Supplier: Cangzhou,Dixin,Roll,Forming,Machine,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Fence panels is mainly used for highway, highway bridge on both sides of the shield used as fence netting, can also be used in airports, ports, docks safety protection, municipal construction of parks, lawns, zoo, ChiHu isolation and protection, roads, residential area, hotel, hotels, supermarkets, entertainment protective and decorative products, etc.
Technical parameters
(1). Suitable material to process: colored armor plate with the bending intensity of 235MPA;
(2). Thickness of the plate: 0.3-0.8mm;
(3).Width of the plate: 160mm(any width)
(4). Productivity: 8-12m/min;
(5). Control system: PLC;
(6). Diameter of the roller: 75mm;
(7).Weight: about 1.5 Ton
(9). Effective area for use: mm;
(10).The main motor power:4KW;
(11)The pump station power:4KW
(12).Kind of drive:chains and sprocket wheel
More machine details for your reference.
Main Parameters
| No. | ||
| 1 | Suitable material | color steel sheet, galvanized steel sheet, aluminium sheet |
| 2 | Material width | 1250mm or as your required |
| 3 | Material thickness | 0.3-0.8 or as your required |
| 4 | Working speed | 20/min, can be 20-25m/min |
| 5 | Main motor power | 5.5kw with cycloidal with reducer |
| 6 | Hydraulic pump power | 4kw |
| 7 | Electrical control system | PLC control system with inverter |
| 8 | Shaft diameter | 75mm |
| 9 | Roller station | 15 rows, depend on your panel profile drawing |
| 10 | Roller | high grade 45# steel, hard chrome plating |
| 11 | Working time | 24 hours |
| 12 | workers | 1-2 only |
| 13 | Cutting head material | Cr 12 mould steel with quenched treatment |
| 14 | Voltage | 380V 3Phase 50Hz or as your required |
| 15 | Weight | 3.5T |
| 16 | The machine size | 7000mm*1500mm*1500mm |
Company Information
After-Sales Service
1. After the machine is ready, we will test the machine and send relevant videos and pictures to you before shipment.
2. The machine is assembled, you do not need to assemble it again, the pump station and PLC are disassembled, you need to wire it yourself, we will bring the relevant manual, the operation is very simple, and we will provide technical support for life, if you have any questions, you can Contact us at any time.
3. When the goods arrive at your port or factory, you can use forklifts and aerial cranes to unload the machine.
4. Regarding the language setting of the machine, it is generally Chinese and English. If you need it, you can set Spanish.
5. The power system is three-phase, and the power connection manual will be brought to you. If manual on-site technical installation is required, the usual cost is 100 dollars per day
6. Before delivery, the machine has been installed in our factory, so you don’t need to worry about the installation, you only need to wire it yourself.
constituent part
