Product Overview

Description


High Quality Screw Juice Extractor, Industrial Cold Press Juicer, Fruit And Vegetable Juicer



Product Detail:

1.Introduction of Perfect price  juice extractor machine:

(1)This machine is suitable for pineapple,apple,pear,and other kernel fruit; kiwi,grape,orange,fresh orange and other berry fruit;tomato,ginger,celery and other vegetable.

(2)Composed of crushing machine and spiral juicing machine.

(3)Completing the juicing and slag discharge process of berries, kernel fruit and vegetables automatically.

(4)Made by stainless steel.

2.Features

(1)spiral Forward extrusion.

(2)Automatic completion of fruit and vegetable juice processing, slag process.

(3)Raw materials touching with food is made of stainless steel.

(4)Can be stand-alone operation, but also can connect production.

3.Application

(1)Fruit and vegetable juice, such as apples, pears, grapes and other pome fruits.

(2)The crushed pineapple, papaya, carrots, etc., Celery, cabbage, barley and other fruits.

(3)The enucleated after bayberry, lychees, blueberries and other stone fruits.

Technical parameters:

Model
Voltage
Motor power
Output
Filter screening mesh
Spiral diameter
Machine material
Machine weight
Machine size
HY-0.5
220V or 380V
1.5KW
500KG/H
0.6mm
Φ87.5mm
304 stainless steel
100KG
1100×265×920mm
HY-1.5
220V or 380V
4KW
1500KG/H
0.6mm
Φ175mm
304 stainless steel
240KG
1560×450×1340mm
HY-2.5
220V or 380V
11KW
2500KG/H
0.6mm
Φ250mm
304 stainless steel
480KG
1980×680×1620mm





The structure,working principle of equipment

1)Structure:



2)working principle

The main component of this equipment is a spiral slag outlet direction along the bottom diameter increase gradually and the pitch decreases, when the material is the spiral propulsion, because the spiral cavity volume reduction, squeeze the material.

Installation operation and maintenance

1.The machine much be installed horizontal,fixed with anchor bolts

2.Operation

When start the machine,should adjust the indenter to make the cyclic annular interval to max,then reduced.When up to the requirements,fixed the bearing seat position with the brake

3.Feeing must,no hard into the fodder,in order to avoid damage the screen mesh.

4.Maintenance

After work, must wash the screen mesh with the water and brus. According the production condition, add one time to clean the mesh. After extractor, should clean all the machine with hot water.





1.png2.JPG3.jpg4.jpg2.jpgspiral juicer extractor machine-2.JPG

Pls feel free to contact me for any question at all times.
