Dongfeng Chaolong Diesel Engine bus 24 Passenger Seats City Bus
- Category: City Bus >>>
- Supplier: Qingdao Seize The Future Automobile Sales Co. Ltd.
Share on (60735351920):
Product Overview
Description
Dongfeng Chaolong Diesel Engine bus 24 Passenger Seats City Bus
Product Description
ITEM | EQ6660PT | |
DIMENSION | LENGTH×WIDTH×HEIGHT(MM) | 6570×2250×2780 |
Front Overhang (MM) | 1160 | |
Rear Overhang (MM) | 2110 | |
Interior Height (MM) | 1860 | |
First Step Height (MM) | 400 | |
WHEELBASE (MM) | 3300 | |
WEIGHT | TOTAL MASS (KG) | 6600 kg |
Max SEATS CAPACITY | 24 seats | |
FRAMEWORK | STRAIGHT BEAM | |
ENGINE | Engine Model | YC4FA115-40 |
Engine Type
| in-line,water-cooled, 6 cylinders, turbocharged, inter-cooled, | |
Position/Fuel | Rear/diesel | |
Max Output | 85 kw | |
Max Torque | 300 Nm/rpm | |
Displacement | 2982ML | |
CHASSIS | Chassis Model | EQ6572KJ4AC |
Gear box | LD535 | |
Clutch | Single plate, dry friction, diaphragm spring, clutch power | |
Front Axle | Dongfeng Dana (2.3T) (Φ320×100) | |
Rear Axles | Dongfeng Dana (4.3T) (Φ320×120) | |
Suspension | Leaf spring front 9 rear 11 | |
Steering | Power steering | |
Brakes | Dual circuit air brake | |
Fuel Tank | 90L | |
Tyres | 7.00-16 | |
Parking Brake | MGM spring brake on drive axle | |
Battery | 6-QA-105X2/ 55A | |
Other | Copper tank and engine preheating device | |
BODY |
Body Type
| Non bearing type |
Interior Trimming
| original | |
Side Window
| fully sealed windows in green color | |
windscreen | Front : laminated glass; Rear : toughened glass | |
Defroster | Defroster with changeable power 24V,130W | |
Windscreen Wiper | opposed electric wiper system | |
| SEATS | Original bus seat |
| OTHERS | PVC floor, flat floor, half drum type sunshade, electric fan, fire extinguisher (4KG) 1, endoscopy, safety hammer (2), before the passenger seat safety handrails or front seats to increase the safety belt, 700A type skylight, knurled handrails, car passenger door, emergency switch air horn |
Packaging & Shipping
Usually Our Truck can be shipped by Ro-ro ship or Bulk ship or Container or Flat rack.
Packing Detail: Ro-Ro or Bulk base on the ship and port in your country. If the truck on the deck,we will spray antirust paint with free. Usually we will put the truck in cabin of the ship.
Delivery Details: 15-35 days after receiving 30% deposit
Shiping Pictures:
Company Information
About Chinatruck.cc
Our Services
We can supply kinds of service to customers according to customers' request:
1,We Will Check Again Before Sending.
2,Spare Parts Supply:
We have our own spear parts departments,have strong production and distribution capability. We can satisfy your demand within 2-7 days. We always do our best to solve the problems, and put our customers' interests in the first place. And We can Supply Spare Parts For Many Brands, Such as SINOTRUK, BEIBEN, FAW, FOTON, IVECO, SHACMAN, SHANTUI, CIMC, DONGFENG and so on.
To see more, kindly click our spare parts website:
FAQ
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
Q:How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q:I want to be your agent in my country , is that ok?
A:It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.
Q: I want the front two tyres are bias tyre and the rear 9 tyres are radial tyres, is it ok?
A: We can make the tyres as your requirement to suit your country's need.
