CNNTNY 5kw permanent magnet generator lifepo4 48v 100ah battery 5kw solar system

Specification

Nominal Voltage

48V

Nominal Capacity(0.5C,25℃)

100Ah

Weight(Approximate)

≤55.6kg

Dimension(Length*Width*Height)

Customized Accept

Terminal

M10 Gold Plated Bolt Hole

Standard Discharge@25℃

Max. Continuous Current

100A

Max. 20 sec. Pulse

200A

Cut-off Voltage

40V±4V

Standard Charge

Charge Voltage

58.2V±0.2V

Recommended Charge Current

10A

Charge Time

10hours

Resistance and rates

Internal Resistance

≤50mΩ

Self-discharge rate

≤5% per Month

General Features

Assembly cell

43184 20Ah

BMS specs

60A-200A
