Product Overview
Description
Wheat Harvester
4LZ-7 Wheat Combine Harvester Main Features
| Strong Power | 1.Equipped with powerful 165HP Name-brand Engine |
| 2.Enhanced Gear Box, working performance reliable | |
Advanced Technology | 3.Lengthened threshing drum with Tangential Flow+Transverse Axial, Threshing separate ability is strong |
| 4.Adoption of Re-threshed system, the effect of threshing is better | |
| 5.New modle cabin easy to operate, broad vision, driving comfortable | |
| 6.Streanline shape for easy maintenance | |
| Cleaning Thoroughly | 7.The bidirectional reciprocating-type screening system with vibrating plate and screen moving in opposite directions reduce the overall vibration and increase the screening capability, providing a better screening effect. |
| 8.Widened cleaning room, higher cleaning efficiency and better effect | |
| Work Efficient | 9.920mm widened conveying axle increase fluent flow of materials and feeding capacity |
| 10.Increasing grain tank with longer continue operate time, Hydrauli discharge auger convenient to unloading |
Technical Parameter
Wheat Harvester Main Technical Parameters
| Overall Parameters | Model | 4LZ-7 |
| Brand Name | Gold Dafeng wheat harvester | |
| Type | Wheel type Self-Propelled Full Feeding | |
| Application | Harvest Wheat / Rice | |
| Working Efficiency | 0.6-1.2 Hm2/h | |
| Dimension (L×W×H) | 6700*3400*3380 mm | |
| Weight | 5640 Kg | |
| Discharging | Hydraulic discharger auger (1.5m) | |
| Grain Tank | 2m3 (1200Kg) | |
| Cabin | Simple / Ordinary / Closed Type | |
| Cutter Header | Cutting width | 2560 mm |
| Feed Volume | 7 Kg/S | |
| Type of Lifting | Hydraulic | |
| Steering | Hydraulic | |
| Lifting of Reel | Hydraulic | |
| Reel type | Eccentricity Spring Tooth | |
| Reel diameter | Φ1000 mm | |
| Engine | Brand | YC |
| Model | YC4A165-T300 | |
| Type | Water-cooled 4-Cycle Vertical Direct Injection | |
| Rated Power | 165 HP (121KW) / 2200 rpm | |
| Fuel Consumption | ≤35 Kg/hm2 | |
| Fuel Tank Capacity | 230 L | |
| Chassis | Min.ground clearance | 320 mm |
| Drive Type | 4×2 | |
| Tyre Size | Driving wheel 15-25 / Guilde wheel 10/75-15.3 | |
| Wheel Track | Driving wheel 1900 mm / Guilde wheel 1810 mm | |
| Wheel Base | 2767mm | |
| Working Speed | 1.6-9.8 Km/H | |
| Walking speed | I gear: 1.6~3.5 km/h | |
| II gear: 3.5~7.7 km/h | ||
| III gear: 9.7~20.5 km/h | ||
| Reverse gear: 1.6~8.0 km/h | ||
| Gearbox Type | Mechanical | |
| Brake Type | Disc | |
| Drive Axle Type | Hydro-static | |
| Threshing | Threshing cylinder | TanTangential Flow + Transverse Axial Flow |
| Cleaning system | Fan+Sieving+re-thresher | |
| Fan | Front blowing + Rear suction | |
| Gravure screen | Grid Type | |
| Conveyor | Chain rack tooth type | |
| Main Performance | Total Loss Rate | Wheat ≤ 1.2 / Rice ≤ 3 |
| Impurities Rate | Wheat ≤ 2 / Rice ≤ 2 | |
| Breakage Rate | Wheat ≤ 1 / Rice ≤ 1.5 | |
| Reliability validity | ≥ 93% |
